Operating Instructions for Your Cobra® 10 Band™ Extra Sensory Detection® RADAR/LASER DETECTOR MODEL E S D – 9 2 1 0 X K Ka V S Nothing comes close to a Cobra™
RADAR/LASER DETECTOR MODEL E S D – 9 2 1 0 Congratulations You’ve made a smart choice by purchasing the ESD-9210 radar/laser detector from Cobra.® Just look at some of the sophisticated features and capabilities your new unit includes: 12V DC POWER JACK ON-OFF/VOLUME control allows you to adjust the volume of the TONE or VOICE alerts. SMARTMUTE™ engine RPM-sensing mute function which reduces false alerts. Button turns SmartMute™ on and off. (Also sets rev point.
Important Information Table of Contents Important information about... Important information about... Federal Laws Governing the Use of Radar Detectors It is not against federal law to receive radar transmissions with your Cobra® radar detector. The Communications Act of 1924 guarantees your right to receive radio transmissions on any frequency.
1 I N S TA L L AT I O N Where to Mount Your Unit You will get optimum performance from your ESD-9210 if you mount it at a point approximately in the center of the vehicle, as low as possible on the front windshield without obstructing the unit's view of the road either to the front or rear. You can also mount it directly on the dashboard. I N S TA L L AT I O N Radar and laser signals pass through glass but not through other materials and objects.
1 O P E R AT I O N • G E T T I N G S TA R T E D I N S TA L L AT I O N Dashboard Mounting 1. Place the detector on the dashboard to find a location where the unit has a clear, level view of the road. The angle can NOT be adjusted after mounting. 4. Attach the detector to the hook-and-loop fastener. You can remove and reattach the unit as often as you like. 2. Remove the paper backing from one side of the hook-and-loop fastener. 1.
O P E R AT I O N • S E T T I N G S When changing the settings on your ESD-9210, please keep in mind: driving in or near urban areas where there are many sources for conflicting X band signals such as microwave towers and automatic door openers. To change settings, follow the procedure in the table below, which indicates what you will see and hear (either in Voice Alert™ or Tone Alert mode) as you complete each step. The factory setting is Highway mode.
3 O P E R AT I O N • S E T T I N G S O P E R AT I O N • S E T T I N G S Muting an Alert Auto Mute Mode SmartMute™ Your ESD-9210 allows you to quickly turn off an audio alert by momentarily pressing the MUTE button. If you press the MUTE button a second time during the alert, the audio alert will be turned back on. Auto Mute will automatically reduce the audio volume of all alerts after 4 seconds for as long as the signal is detected.
3 O P E R AT I O N • S E T T I N G S O P E R AT I O N • S E T T I N G S What to Remember While Using SmartMute™ SmartMute™ works with both City and Auto Mute modes. Whenever your engine revs are below the activation point, the dot next to the large character on the right side of the display will remain lit. Above the activation point, the dot will blink twice every 2 seconds.
3 O P E R AT I O N • S E T T I N G S O P E R AT I O N • S E T T I N G S Voice/Tone Setting VG-2 Alert Audio Setting You can set your ESD-9210 to sound alerts with either a voice or a tone. You change settings by using the MUTE button. The ESD-9210 is undetectable by police VG-2 detection devices, and will alert you when such a device is in use near your vehicle. During the alert, the unit continues to detect other signals. You can choose whether or not you want your unit to sound VG-2 alerts.
4 DETECTION DETECTION Signals Detected The tables on the following pages show you the types of signals your ESD-9210 will detect, as well as the voice and visual alerts it provides for each one. Audio Alerts In Voice Alert™ mode you will first hear several tones, then a voice message announcing the type of signal detected, followed by more tones. In Tone Alert mode, you will hear the tones only.
4 DETECTION Safety Alert® DETECTION Type of Signal Voice Visual Display emergency vehicles ”emergency vehicle approaching“ ”road hazard ahead“ "train approaching" S road hazards trains PLEASE NOTE: There are different tones for each Safety Alert ® S S 4 Instant-On Detection Your ESD-9210 is designed to detect instant-on speed monitoring signals, which can suddenly appear at full strength. You should take appropriate action immediately whenever an alert is given.
5 U N D E R S TA N D I N G R A D A R & L A S E R Radar Speed Monitoring Systems Three band frequencies have been approved by the Federal Communications Commission (FCC) for use by speed monitoring radar equipment: X band 10.525 GHz K band 24.150 GHz Ka band 33.400-36.00 GHz Your ESD-9210 detects signals in all three radar bands. VG-2 emergency vehicle or train, or a stationary road hazard.
6 MAINTENANCE & SERVICE Maintenance of Your Radar Detector Your ESD-9210 is designed and built to give you years of trouble-free performance without the need for service. No routine maintenance is required. If your unit does not appear to be operating properly, please follow these troubleshooting steps: Make sure the power cord is properly connected. Make sure the socket of your vehicle's cigarette lighter is clean and free of corrosion.
WA R R A N T Y S P E C I F I C AT I O N S Wa ar rra 8 nty 1 Ye 7 QUALITY SEAL Cobra Electronics Corporation 6500 West Cortland Street, Chicago, Illinois 60707 www.cobra.com Band Frequencies QUALITY SEAL COBRA ELECTRONICS CORPORATION ® warrants that its Cobra 10 Band™ Radar/Laser Detectors, and the component parts thereof, will be free of defects in workmanship and materials for period of one (1) year from the date of first consumer purchase.
9 10 ORDER FORM OPTIONAL ACCESSORIES Item # 420-030-N-001 420-026-N-001 545-139-N-001 CLP-2B You can find these fine accessories at your local Cobra® dealer. If you wish, you can order directly from Cobra.® To order by phone Call 773.889.3087 (Press 1 from the main menu 8 a.m.-6 p.m. M-F CST. ) To order by mail or fax Please fill out order form on next page, and mail/fax directly to Cobra.
The Cobra® line of quality products includes: CB radios ® microTALK radios Radar/Laser Detectors ® Safety Alert Traffic Warning Systems Accessories HighGear™ Accessories For more information or to order any of our products, please visit our website: www.cobra.com Click “shop Cobra®” Nothing comes close to a Cobra™ Printed in Korea Part No.
