User's Manual

Distortion
Frequency Response
SNR
Output Power
Sound track Splitter
Input Impedance
Voltage Gain
Input Signal level Rating
Damping Friction
Power
Frequency Loss
Size
<1%
20Hz~20kHz
>55dB
6W
80dB
600
14
500mV
40
15V/800mA
3%
4.25"x9.63"x4.5"
(WHD)
AC/DC
CS-P95
2.4GHz WIRELESS SPEAKER SYSTEM
INSTRUCTION
FEATURES SUMMARY
MAIN PARAMETER GUIDE LINE
IMPORTANT SAFETY INSTRUCTIONS
LOCATION OF CONTROLS
TV set
VCR
Radio
Computer
2.4GHz ANALOG TECHNOLOGY
HIGH FIDELITY SOUND THAT PENETRATES THROUGH WALLS AND CEILINGS
TRANSMISSION OF MUSIC OVER 200 FEET
OUTPUT POWER 10 WATT RMS PER CHANNEL
PLL SYSTEM PREVENTS RECEPTION FREQUENCY FROM SHIFTING/DRIFTING
TRULY 100% WIRELESS
AC/DC OPERATIONAL
WITH BUILT-IN RECHARGEABLE BATTERIES (OPTIONAL)
OPTIONAL REMOTE CONTROL
FREQUENCY RESPONSE: 20 Hz ----20 KHz
Channel display
Scan button
Volume level knob
Sound track switch
Charge ON/OFF
switch
Power ON/OFF
switch
DC IN jack
Audio in jack
Battery door
Channel display LED
Scan button
DC In jack
Audio In jack
Connect the transmitter
The transmitter is equipped with two jacks, which allows for connection to
the specified output jacks: DC IN to the AC power, and AUDIO IN to the LINE
OUT jacks of your connected equipment.
AC Adapter 9V 300mA)(
The wall AC Adapter outlet
Audio connect Line
The transmitter
The audio/video component
NOTE: If your audio/video component have right&left sound track stereo
plug system, you can use the audio connect line and the audio conversion
line to connect it.
To the audio in jack
in transmitter
To the audio in jack of the audio
conversion line
To the right/left
sound track in the
audio/video
component
Customer Service Dept.
1-800-681-2629
1-718-416-3197
[e-mail]
SCAN
OPERATING THE SYSTEM
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Use only with class 2 power source DC 9V 300mA.
4. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
5. Do not use this product near water; for example, near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
6. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to
the product.
7. Slots and openings in the cabinet back or bottom are provided for ventilation. To protect it from overheating,
these openings must not be blocked or covered. The openings should never be blocked by placing the product
on the bed, sofa, rug or other similar surfaces. This product should never be placed near or over a radiator or heat
register. This product should not be placed in an enclosed environment unless proper ventilation is provided.
8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be pinched or
walked on.
9. Do not overload wall outlets and extension cords as this can result in risk of fire or electrical shock.
10. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or
short out parts that could result in a risk of fire or electrical shock. Never spill liquid of any kind on the product.
11. To reduce the risk of electrical shock, do not disassemble this product. Instead take it to a qualified service person
when service or repair work is required. Opening or removing covers may expose you to dangerous voltages or
other risks. Incorrect re-assembly can cause electrical shock when the appliance is subsequently used.
12. Unplug all cords and refer servicing to qualified service personnel under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions. Adjust only those controls
covered in the operating instructions. Improper adjustment of other controls may result in damage and require work
by a qualified technician to restore the product to normal operation.
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric
shock from lightning.
14. Do not use a telephone to report a gas leak in the vicinity of the leak.
1. Use only the type and size of batteries specified in the users manual.
2. Do not dispose of the batteries in a fire. The cells may explode. Check with local codes for possible special
disposal instructions.
3. Do not open or mutilate the batteries. Released electrolyte is corrosive and may cause damage to the eyes or skin. It
may be toxic if swallowed.
4. Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets
and keys. The battery or conductor may overheat and cause burns.
5. Do not attempt to recharge the batteries with or identified for use with this product. The batteries may leak
corrosive electrolyte or explode.
6. Do not attempt to rejuvenate the batteries provided with or identified for use with this product by heating them.
Sudden release of the battery electrolyte may occur causing burns or irritation to eyes or skin.
7. When replacing batteries, all batteries should be replaced at the same time. Mixing fresh and discharged batteries
could increase internal cell pressure and rupture the discharged batteries.
8. When inserting the batteries into this product, the proper polarity or direction must be observed. Reverse
insertion of batteries can cause charging, which may result in leakage or explosion.
9. Remove the batteries from this product if the product will not be used for a long period of time (several months or
more) since during this time the batteries could leak, damaging the product.
10. Discard "dead" batteries as soon as possible since they are more likely to leak in a product.
11. Do not store this product, or the batteries provided with or for identified use with this product, in high temperature
areas.
12. If your product uses a rechargeable battery, charge the battery(ies) only in accordance with the instructions and
limitation specified in the User Manual.
IF YOUR PRODUCT UTILIZES BATTERIES, THE FOLLOWING ADDITIONAL PRECAUTIONS SHOULD BE
OBSERVED:
SAVE THESE INSTRUCTIONS
injury, fire, or electrical shock. When using this product, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, including the following:
This symbol is to alert you to important operating or servicing instructions that may appear in the
user's manual. Always follow basic safety precautions when using this product to reduce the risk of
FCC RULES
This equipment has been tested and found to comply with the limits for a
digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
--
--
--
--
CAUTION:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance will void the user's authority to operate the
equipment. Any change to the equipment will void FCC grant.
