Troubleshooting guide

1336 PLUS II - 6.16 - September, 2001
Troubleshooting and Error Codes 3-9
Table 3.B
HIM Upload/Download Errors
Fault Name Error Displayed Probable Cause Action
HIM -> Drive ERROR 1 The HIM calculated a checksum for the file to be
downloaded, then checked the EEPROM
checksum of the download. The checksums did
not match, indicating the file stored in the HIM is
invalid and the download was not successful.
Upload a valid, uncorrupted file from the
source drive and then repeat the download.
ERROR 2 The number of parameters in the HIM file is
different than the number of parameters in the
drive file. The smaller of the two numbers is the
number of parameters downloaded. The last
downloaded parameter number is displayed.
Verify that the correct file is being
downloaded to the correct drive, then press
the Enter key.
Manually reprogram the parameters whose
numbers are higher than the last number
downloaded or whose values were
incorrect.
ERROR 3 The file in the HIM is for a different type of drive
than the drive to which it is connected (i.e. 1336
PLUS file to 1336 IMPACT drive). Downloads can
only occur between like drive types.
None - Download not allowed.
ERROR 4 The value just transferred to the drive is an illegal
value (out of range, too high or too low) for the
parameter.
Record the parameter number displayed
and then press the Enter key to continue
the download. Manually reprogram all
recorded parameters after the download is
complete.
ERROR 5 The download was attempted while the drive was
running.
Stop the drive and repeat the download
attempt.
ERROR 6 The file in the HIM is for a different HP or voltage
drive than the drive to which it is connected (i.e.
1336 PLUS 10 HP file to 1336 PLUS 15 HP drive).
If the download is desired, press the Enter
key. If not desired, press the ESCape key to
end the download
Drive -> HIM ERROR 1 The HIM calculated a checksum as the file was
uploaded and compared it to the HIM file
checksum stored after the upload. The checksums
did not match, indicating the upload was not
successful and the HIM file is now corrupted.
Repeat the Upload.
