Setting Description Example (Actual settings may vary
from examples listed below)
each label printed.
Advance With PRESENTLABEL ON, the distance
that a label is advanced, in hundredths of
an inch
Advance: 15
Reverse With PRESENTLABEL ON, the distance
that a label is retracted, in hundredths of
an inch
Reverse: 20
Print Mode DT indicates direct thermal printing, TT
indicates thermal transfer printing
Print Mode: DT (DT)
Print Speed Displays the current printing speed setting. Print Speed: HIGHSPEED
Report Level Sets the manner in which the printer
reports recoverable errors.
Report Level: 2
Shift left: (1/100) inches) Distance the image is shifted to the left, in
hundredths of an inch
Shift left: (1/100) inches): 0
Text Buffer:
Size Size of the text buffer Size:65535
Overflow Overflow value for the text buffer Overflow: 1024
User Feedback Shows the status of VARIABLE
USER_FEEDBACK
User Feedback: OFF
Width Default label width (approximate), in
hundredths of an inch
Width: 425 (864 dots)
Auxiliary Language Secondary Language Processor Aux. Language : NONE
