• CPL programming language
• Parallel, Serial, USB-A, and USB-B communication ports
• USB-A Host Control
• Adjustable position transmissive and reflective index sensing technology
to accommodate a wide variety of print media.
• Cognitive® printer driver for Windows™ NT, 2000 and XP operating
systems.
• NiceLabel® SE - Windows™ based WYSIWYG on-screen label design
and print application demo software.
Optional Features
• 300 dpi Print Resolution (12 dots/mm)
• Ethernet 10/100 Base-T interface
• Thermal Transfer Printing
• PCL (4” printers only)
Printing Specifications
Nominal
Printer Size
2” Ci or Cxi 4” Ci or Cxi
Print
Resolutions
203 dpi
Standard
300 dpi
Optional
203 dpi
Standard
300 dpi
Optional
Max Print
width
2.118"
(53.8mm)
2.205"
(56.0mm)
4.094"
(104.0mm)
4.153"
(105.5mm)
Print
Speeds
4-6 ips Ci 4-8
ips Cxi
2-6 ips Ci 2-
6 ips Cxi
4-6 ips Ci 4-8
ips Cxi
2-6 ips Ci 2-6
ips Cxi
Max Print
Lengths
322” (8179mm) 218”
(5537mm)
322” (8179mm) 153” (3886mm)
Print
Position
Tolerance
±0.0625" (1.6mm) Left and right
