Fyrestorm™ Ti Fyrestorm™ SS CSA B140.9.2 Portable Pressurized Type Liquid Petroleum Fuelled Camp Stoves Multi-Fuel Stove Instructions for use ® © 2006 The Coleman Company, Inc. www.coleman.com Models 9770 and 9775 Reflector disc and windscreen not shown. U.S. Pat. No. 5,370,527 Canada Pat. No. 2,089,804 and other patents pending. IMPORTANT Read this manual carefully before assembling, using or servicing these stoves. Keep this manual for future reference.
This manual contains important information about the assembly, operation and maintenance of this outdoor multi-fuel appliance. General safety information is presented on this page and is also located throughout these instructions. Particular attention should be paid to information accompanied by the safety alert symbol “ DANGER”, “ WARNING”, “ CAUTION”. FOR YOUR SAFETY If you smell gas: 1. Do not attempt to light appliance. 2. Extinguish any open flame. 3. Disconnect from fuel supply.
DANGER WARNING This multi-fuel appliance may be fueled by LPG, or Coleman® Liquid Fuel, or unleaded gasoline. • EXPLOSION - FIRE HAZARD Warnings specific to LPG fuel: Dangers specific to Liquid fuel: • LPG is invisible, odorless, and flammable. An odorant is normally added to help detect leaks and can be described as a ”rotten egg” smell. The odorant can fade over time so leaking gas is not always detectable by smell alone. • LPG is heavier than air and leaking LPG will sink to the lowest level possible.
DANGER WARNING • CARBON MONOXIDE HAZARD • This stove is a combustion appliance. All combustion appliances produce carbon monoxide (CO) during the combustion process. This product is designed to produce extremely minute, non-hazardous amounts of CO if used and maintained in accordance with all warnings and instructions. Do not block air flow into or out of the stove. • Carbon Monoxide (CO) poisoning produces flu-like symptoms, watery eyes, headaches, dizziness, fatigue and possibly death.
1 Becoming Familiar with your Coleman® Stove Thank you for purchasing your new Coleman® multi-fuel stove. This stove is a high performance multi-fuel cooking appliance. Operation and control of liquid fuel is different than LPG. We recommend operating your new stove in a safe location outside your home to familiarize yourself with its multi-fuel operation before your next outdoor experience. Helpful Hints • Consider carrying your spare parts and tools for stove servicing.
USING STOVE WITH COLEMAN® FUEL BOTTLE 2 Identification (Coleman® Fuel Bottle) READ AND FOLLOW ADDITIONAL INSTRUCTIONS ON THE FUEL BOTTLE. NOTE: The reflector disc and windscreen are not illustrated in the set up instructions. This is so the features of the stove may be clearly visible and identified. Read about the reflector disc and windscreen in Sections 1 and 15. DANGER • CARBON MONOXIDE HAZARD • For outdoor use only.
3 Stove Set Up NOTE: The reflector disc and windscreen are not illustrated in the set up instructions. This is so the features of the stove may be clearly visible and identified. Read about the reflector disc and windscreen in Sections 1 and 15. ■ Unfold stove legs to detent stops and place on reflector disc. (Fig. 3, 4, and 5) FIG. 3 4 FIG. 4 FIG. 5 To Fill Tank (Coleman® Fuel Bottle) NEVER FILL OR LIGHT STOVE INSIDE HOUSE, CAMPER, OR TENT. ■ Unscrew bottle from black pump assembly (Fig. 6 and 7).
5 To Pump (Coleman® Fuel Bottle) ■ Make sure FUEL VALVE is fully “OFF” (Fig 12). ■ Connect hose to threaded fitting on fuel bottle, making sure the bottle is lying on its side with the fuel valve up. Hand tighten the connection (Fig. 13). ■ Place thumb over hole in PUMP KNOB and pump approximately 40 full strokes (Fig 14). Adequate air pressure is important, do not over pump. FIG. 12 6 FIG. 13 FIG. 14 Leak Check (Coleman® Fuel Bottle) WARNING WARNING • Perform leak test outdoors.
7 To Light (Coleman® Fuel Bottle) NEVER FILL OR LIGHT STOVE INSIDE HOUSE, CAMPER, OR TENT. ■ Make sure fuel bottle is lying level on its side with the FUEL VALVE up (Fig. 16). ■ Turn flame adjuster back and forth several times to clean generator tip (Fig. 19). ■ Turn flame adjuster to “High/Light” (Fig. 17). ■ Hold lighted match at burner and then open fuel valve (Fig. 16 and 18). ■ CAUTION: If stove burns with a high yellow flame or if liquid fuel appears in the burner, immediately turn FUEL VALVE “OFF.
USING STOVE WITH COLEMAN® LPG CANISTER 9 Identification (LPG Canister) READ AND FOLLOW ADDITIONAL INSTRUCTIONS ON THE CANISTER SUPPORT. NOTE: The reflector disc and windscreen are not illustrated in the set up instructions. This is so the features of the stove may be clearly visible and identified. Read about the reflector disc and windscreen in Sections 1 and 15. NOTE: Use only Coleman® 3250 Butane/Propane Fuel. DANGER • CARBON MONOXIDE HAZARD • For outdoor use only.
Set Up (LPG Canister) ■ Unfold canister support legs to detent stops (Fig. 25, 26, and 27) FIG. 25 FIG. 26 FIG. 27 ■ Make sure that the FUEL VALVE on the canister support is fully closed (turned fully clockwise) (Fig. 28). ■ Screw LPG canister onto canister support until fully seated (Fig. 29). ■ Insert threaded fitting on end of stove fuel hose into the female threaded coupler on the canister support (Fig. 30). Hand tighten the connection. FIG. 28 FIG. 29 FIG.
Leak Check (LPG Canister) WARNING WARNING • Perform leak test outdoors. • Extinguish all open flames. • NEVER leak test when smoking. • Do not use the outdoor stove until connection has been leak tested and does not leak. • BURN HAZARD • Never leave stove unattended when hot or in use. • Keep out of reach of children. ■ Make sure FUEL VALVE is fully “OFF” . ■ CHECK FOR LEAKS in one or more ways: Apply soapy water to “O” Ring connections as indicated (Fig. 32).
DANGER • EXPLOSION - FIRE HAZARD • LPG is heavier than air and can accumulate in low places. If you smell gas, leave the area immediately. • Always attach or detach fuel canisters outdoors; never while stove is lighted, near flame, pilot lights, other ignition sources or while stove is hot to touch. • This stove is very hot during use and can ignite flammables too close to the burners. Keep flammables at least 24 inches from the sides and 48 inches from the top of the stove.
16 To Store ■ Make sure stove is cool. ■ Move stove away from flame (including pilot lights) and other ignition sources. ■ If using the fuel bottle, disconnect the fuel hose at the threaded fitting attached to the fuel bottle. ■ If using an LPG canister, disconnect the fuel hose at the threaded fitting attached to the canister support and then remove the LPG canister from the canister support. ■ Replace the protective caps onto the threaded fittings. ■ The stove may be folded for compact storage (Fig.
17 Troubleshooting Symptom Problem Solution Burner will not light or flame selfextinguished. Fuel bottle empty. Refill fuel bottle 2/3 full with clean and fresh Coleman® fuel or unleaded fuel. Burner will not light or flame is low or flame selfextinguished. Little or no pressure in fuel Check connections for leaks and bottle. pump 40 strokes. Yellow flame. Excess fuel in burner. A yellow flame is normal until the generator warms up.
Replacement Parts List Item Part No. Description 1 2 3 9770-5051 9770-5551 R9770-501 4 5 9770-5611 9770-5081 Plunger Assembly Pump and Valve Assembly Stove Maintenance Kit (includes one item on the next page) Service Parts Kit (includes several items on the next two pages) Fuel Bottle Assembly (22 fl. oz.
Replacement Parts List Item 6 7 8 9 10 Part No.
Replacement Parts List Item 11 12 13 14 Part No.
Things You Should Know Warranty Limited Five Year Warranty The Coleman Company, Inc. (“Coleman”) warrants that for a period of five years from the date of original retail purchase, this product will be free from defects in material and workmanship. Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. Replacement will be made with a new or remanufactured product or component.
