2-8 Troubleshooting Flowcharts
7. No Video, Part 3
See codes
or flashing
lights or hear
beeps?
Restart computer.
Turn off computer and
disconnect power. Replace
components in system
one at a time starting with
hard drive. Test system
after each replacement for
video or beeps.
Y
Replace
video card.
Caution: Power is continuous to the system board and power supply
even when the power switch is turned off. To prevent damage to the unit,
disconnect the power cord from the power source or the unit before
beginning disassembly procedures.
From Page 2-7,
No Video, Part 2
N
Integrated
video?
N
Replace
system board.
Video OK?
Y
N
Done.
