Environment Management:
SAF-TE/S.E.S. support
Supported. The SAF-TE/S.E.S. modules can be
connected to the drive channel, the controller will
detect errors from SAF-TE/S.E.S. devices or notify
drive failure via SAF-TE/S.E.S..
• Both SAF-TE/S.E.S. via drive and device-self-
interfaced are supported.
• Redundant SAF-TE/S.E.S. devices are
supported
• Multiple S.E.S. devices are supported
Dynamic on-lining of
enclosure services
Once an expansion unit (JBOD) with supported
monitoring interface is combined with a RAID system,
its status will be automatically polled.
SAF-TE/S.E.S. polling
period
User configurable (50ms, 100ms, 200ms, 500ms,
1~60sec)
ISEMS (Infortrend Simple
Enclosure Management
Service)
Supported.
Multiple SAF-TE/S.E.S.
modules on the same
channel
Supported.
Multiple SAF-TE /S.E.S.
modules on different
channels
Supported.
Mapping SAF-TE/S.E.S.
device to host channel for
use with Host-based SAF-
TE/S.E.S. Monitor
Supported.
Dual-LED drive status
indicators
Supported. Both single-LED and dual-LED drive
status indicators are supported.
SAF-TE/ S.E.S. Temperature
value display
Supported. Display the temperature value provided
by enclosure SAF-TE module (if available).
Fault-bus support
Provides the simplest implementation for the
enclosure management. All fault-bus input/output
signals are active-high/active-low user adjustable.
On-board controller voltage
monitors
Supported. Monitors the 3.3V, 5V, and 12V voltage
status. Event trigger threshold user configurable.
On-board controller
temperature sensors
Supported. Monitors the CPU and board
temperature status. Event trigger threshold user
configurable.
Enclosure redundant power
supply status monitoring
Supported. Fault-Bus/SAF-TE/S.E.S./ISEMS
Enclosure Fan status
monitoring
Supported. Fault-Bus/SAF-TE/S.E.S/ISEMS
Enclosure UPS status
monitoring
Supported. Fault-Bus/SAF-TE/S.E.S/ISEMS
Enclosure temperature
monitoring
Supported. Fault-Bus/SAF-TE/S.E.S/ISEMS
