Deleting a Channel ID
Press ENT on an existing host channel
ID you want to delete. Press ▼ or ▲ to
choose “Delete Channel SCSI ID," then
press ENT.
Press ENT for two seconds to confirm.
IMPORTANT!
•
Every time you make changes to channel IDs, you must reset the
controller for the configuration to take effect.
•
The reserved IDs for SCSI-based controllers are shown below:
Single controller configuration (SCSI-based controllers):
Drive channels – “7”
Redundant controller configuration:
Drive channels – “8” and “9”
For IDs reserved in different controller configurations, please refer to the
hardware manual that came with your system. For controllers
connected through back-end PCBs, firmware can detect its board type
and automatically apply the preset IDs. There is no need to set IDs for
these models.
•
In single controller mode, you should set the Secondary Controller’s ID
to “NA.” If a secondary controller exists, you need to set an ID for it on
each of your drive channels.
•
Multiple target IDs can be applied to Host channels while each Drive
channel has only one or two IDs (in redundant mode).
•
At least a controller’s ID has to be present on each channel bus.
Setting a SCSI Channel’s Primary ID - Drive Channel
Press ENT for two seconds to enter the
Main Menu. Press ▼ or ▲ to select
"View and Edit SCSI Channels," then
press ENT.
View and Edit
SCSI Channels ↕
Delete ID=2
Primary Ctlr ?
Delete Channel
SCSI ID ..
