QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Overview The HP ProLiant SL250s Gen8 Server is part of the HP ProLiant SL6500 Scalable System of server solutions optimized for the Hyperscale and High Performance Computing market segments. The server series is designed to reduce solution costs, maximize power efficiency, and to ease customer serviceability.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features NOTE: For the Standard Features shipped in the Factory Integrated Models, please see the "Configuration Information - Factory Integrated Models" section. Processor Entry Processors One of the following NOTE: All support up to 1066MHz memory speeds. depending on Model Intel® Xeon® E5-2609 (2.4GHz/4-core/10MB/6.4GT-s QPI/80W) Intel® Xeon® E5-2603 (1.8GHz/4-core/10MB/6.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features Cache Memory One of the following depending on Model 20MB (1x20MB) Level 3 NOTE: For Eight-core processors. 15MB (1x15MB) Level 3 NOTE: For Six-core processors. 10MB (1x10MB) Level 3 NOTE: For Quad-core processors. 5MB (1x5MB) Level 3 NOTE: For Dual-core processors. Chipset Intel® C600 Series Chipset Intel® E5-2600 Processor Family NOTE: For more information regarding Intel® chipsets, please see the following URL: http://www.intel.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features Network Controller HP Ethernet 1Gb 2-port 361i Expansion Slots Expansion Slots # 1 2 Technology Bus Width* Width PCIe 3.0 PCIe 3.0 x8 x16 Connector Width x8 x16 Form Factor Notes Low Profile slot Half-length, fullheight slot *Indicates the number of physical electrical lanes running to the connector. NOTE: Two PCIe 3.0 expansion slots: (1) Half-length, full-height slot and (1) low-profile slot.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features Maximum Internal Storage 2U Half Width tray Hot Plug SATA SFF 2.5" 4.0 TB 2 x 1TB Hot Plug SAS SFF 2.5" 4.0TB 2 x 1TB Hot Plug SATA SSD 2.5" 1.6TB 2 x 400GB Hot Plug SAS SSD 2.5" 3.2TB 2 x 800GB Quick Release (Non-Hot 4.0TB 4 x 1TB Plug) SATA 2.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features Server Power Cords One 6' Highline (IEC-IEC) power cord ships standard NOTE: HP ProLiant SL servers are primarily connected to PDU's in data center racks so they ship standard with only a PDU power cord (416151-B21). If a user wishes to power a ProLiant SL server using a 110V receptacle (NEMA-15), the NEMA power cord must be ordered separately.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features System Fans HP s6500 Redundant Fan Kit NOTE: This kit includes only 1 fan NOTE: This selection must be ordered in quantities of 8 (PN 617856-B21) HP s6500 Non-Redundant Fan Kit NOTE: This kit includes only 1 fan NOTE: This selection must be ordered in quantities of 8 (PN 617858-B21) NOTE: all 8 fan bays must be populated with either redundant or non-redundant fans NOTE: mixing and matching of fans is not allowed Operating Systems and Vi
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features configuration history; Health and service alerts; Easy export and upload to Service and Support. HP Intelligent Provisioning (previously known as SmartStart): HP Intelligent Provisioning offers the ability for out-of-the box single-server deployment and configuration without the need for media. NOTE: For more information, visit: http://www.hp.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Standard Features Security Power-on password Keyboard password QuickLock, Network Server Mode Serial interface control Administrator's password iLO 4 (Integrated Lights-Out 3) has 12 customizable user accounts and SSL encryption iLO 4 can be disabled via a Global Setting iLO Advanced supports directory services integration Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Optional Features HP Insight management software HP Insight Control HP Insight Control, a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, remote control, and optimize your IT infrastructure through a single, simple management console.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Optional Features High Performance Clusters HP Cluster Platforms HP HPC Interconnects HP Cluster Platforms are specifically engineered, factory-integrated largescale ProLiant clusters optimized for High Performance Computing, with a choice of servers, networks and software. Operating system options include specially priced offerings for Red Hat Enterprise Linux and SUSE Linux Enterprise Server, as well as Microsoft Windows HPC Server.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Optional Features HP Enterprise Configurator The HP eConfigure Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance. http://www.hp.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Service and Support Service and Support HP Technology Services for Industry Standard Servers and BladeSystem Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who understands your increasingly complex business technology environment. That's why it makes sense to team up with the people who know HP infrastructure hardware and software best - the experienced professionals at HP Services.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Service and Support Standard Care Standard Care: Service recommendation that maintains high level of server availability HP ProLiant Server Hardware Installation Provides for the basic hardware installation of HP branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Service and Support HP Support Center Personalized online support portal with access to information, tools and experts to support HP business products. Submit support cases online, chat with HP experts, access support resources or collaborate with peers. Learn more http://www.hp.com/go/hpsc HP's Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for live support.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Pre-configured Models NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory Integrated Models" section. NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section of this QuickSpecs. NOTE: HP does not allow factory integration of options into pre-configured models.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Configuration Information - Factory Integrated Models NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on configurable product offerings and requirements. NOTE: Configure-to-order (CTO) servers must start with a CTO Chassis.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Configuration Information - Factory Integrated Models HP Memory HP SL250s Gen8 Intel® Xeon® E5-2630 (2.30GHz/6-core/15MB/95W) FIO Processor Kit HP SL250s Gen8 Intel® Xeon® E5-2620 (2.0GHz/6-core/15MB/95W) FIO Processor Kit HP SL250s Gen8 Intel® Xeon® E5-2630L (2.0GHz/6-core/15MB/60W) FIO Processor Kit Performance Processors NOTE: All support up to 1600MHz DDR3 memory speeds. HP SL250s Gen8 Intel® Xeon® E5-2680 (2.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Configuration Information - Factory Integrated Models HP 16GB (1x16GB) Dual Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory Kit Unbuffered with ECC DIMMs (UDIMMs) HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low Voltage Memory Kit HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low Voltage Memory Kit HP 8GB (1x8GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low Voltage Memory Kit NOTE: For d
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Core Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information. SL250 SFF Internal Enablement Kit 679991-B21 HP Unique Options NOTE: The SFF enablement kit allows for up to four SFF HDD to be implemented in place of the three GPUs.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Core Options HP Memory HP Hard Drives NOTE: HP memory from previous generation servers are not qualified or warranted with this HP ProLiant Server. HP SmartMemory is required to realize the memory performance improvements and enhanced functionality listed in this document for Gen8. For additional information, please see the HP SmartMemory QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Core Options HP 300GB 6G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive HP 146GB 6G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive HP 72GB 6G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive SAS Hot Plug Smart Drive SFF (2.5-inch) Midline Drives HP 1TB 6G SAS 7.2K rpm SFF (2.5-inch) SC Midline 1yr Warranty Hard Drive HP 500GB 6G SAS 7.2K rpm SFF (2.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Core Options HP Networking HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Quick-release Dual Port Enterprise 3yr Warranty Hard Drive SATA Non-Hot Plug SFF (2.5-inch) Enterprise Mainstream - with quick-release (QR) carrier HP 400GB 3G SATA MLC SFF (2.5-inch) Quick-release Enterprise Mainstream 3yr Wty Solid State Drive HP 200GB 3G SATA MLC SFF (2.5-inch) Quick-release Enterprise Mainstream 3yr Wty Solid State Drive HP 100GB 3G SATA MLC SFF (2.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Core Options HP InfiniBand HP Power Supplies HP InfiniBand 4X QDR ConnectX-2 PCIe G2 Dual Port HCA QLogic InfiniBand 4X QDR PCI-E G2 Dual Port HCA HP InfiniBand FDR/EN 10/40Gb Dual Port 544FLR-QSFP Adapter NOTE: Dual port ConnectX-3 FDR/QDR IB or 40/10GbE. No IB Enablement Kit required. HP InfiniBand QDR/EN 10Gb Dual Port 544FLR-QSFP Adapter NOTE: Dual port ConnectX-3 QDR IB or 10GbE. No IB Enablement Kit required.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options HP SL Advanced Power Manager The SL Advanced Power Manager is an optional rack level solution for the HP ProLiant SL6500 which enables server-level DC (or hardware) power on and off and serverlevel monitoring. In addition, the SL APM will automatically discover SL hardware components which are connected into the SL APM solution.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options on Download button). NOTE: Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single set of activation keys. NOTE: For additional License Kits, including electronic licensing options, please see the QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/13019_na/13019_na.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options High Performance Clusters HP Cluster Management Utility HP Insight Cluster Management Utility 1yr 24x7 Flexible License HP Insight Cluster Management Utility 3yr 24x7 Flexible License NOTE: These part numbers can be used to purchase one certificate for multiple licenses and support with a single activation key. Each license is for one node (server).
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options NOTE: One must configure a minimum of 4GB of memory per CPU when GPU's are installed NOTE: For additional license kits please see the QuickSpecs at: http://h18004.www1.hp.com/products/quickspecs/13743_na/13743_na.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options HP Rack Series HP Rack Options HP Rack 10000 G2 Series (Carbon/Graphite Metallic) HP 10642 G2 1200mm deep Shock Rack HP 10647 G2 1200mm deep Shock Rack NOTE: It is mandatory to use a shock pallet when shipping racks with equipment installed. NOTE: Please see the QuickSpecs for Technical Specifications and additional information: http://h18000.www1.hp.com/products/quickspecs/12402_na/12402_na.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options HP 3 year 24x7 24 hour Call to Repair with Defective Media Retention ProLiant s6500 Hardware Support HP 3 year 4 hour 13x5 ProLiant s6500 Hardware Support HP 3 year 4 hour 13x5 with Defective Media Retention ProLiant s6500 Hardware Support HP 3 year 4 hour 24x7 ProLiant s6500 Hardware Support HP 3 year 4 hour 24x7 with Defective Media Retention ProLiant s6500 Hardware Support HP 3 year 6 hour 24x7 Call to Repair ProLiant s6500 Hardware S
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Additional Options NOTE: For more information, customer/resellers can contact: http://www.hp.com/services/carepack.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Memory HP ProLiant SL250s Gen8 Server NOTE: Memory configurations listed do not apply to "Factory Integrated Models". NOTE: Chart does not represent all possible memory configurations. DDR3 memory population guidelines For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool: www.hp.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Memory information, please see the HP SmartMemory QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html. For memory population rules and additional memory guidelines, please see the SL250 Gen8 user guide at http://www.hp.com/support.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Memory 2GB = 2048MB 4GB = 4096MB 8GB = 8192MB 16GB = 16384MB DDR3 memory options part number decoder Following are memory options available from HP: HP Memory NOTE: HP memory from previous generation servers are not qualified or warranted with this HP ProLiant Server. HP SmartMemory is required to realize the memory performance improvements and enhanced functionality listed in this document for Gen8.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Memory HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low Voltage Memory Kit HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low Voltage Memory Kit HP 8GB (1x8GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low Voltage Memory Kit NOTE: For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool: www.hp.com/go/ddr3memory-configurator.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Storage 2U Tray 1-4 5 1-4 Up to four 2.5" hot plug hard drive bays 5 Up to four additional 2.5" non hot-plug drives can be configured when the SFF Hard Drive Enablement Kit is implemented in place of the included GPU kit Drive Support Hard Drives NOTE: The components of a storage subsystem (e.g.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Storage 1TB 6G SATA 7.2K 500GB 6G SATA 7.2K Quantity Supported Up to 4 Position Supported 1-4 Controller HP H220i Host Bus Adapter 6G SATA Quick Release SFF (2.5-inch) Midline (MDL) Drives Quantity Position Supported Supported Controller 1TB 6G SATA 7.2K Up to 4 7 HP H220i Host Bus Adapter 500GB 6G SATA 7.2K 6G SAS MLC Hot Plug SFF (2.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Technical Specifications System Unit Chassis Dimensions (H x 6.96 x 17.638 x 35.236in (17.68 x 44.8 x 89.55cm) W x D) Add fan extension kit (with bezel) Maximum 220lb (99.8kg) Weight (approximate) (all hard drives, power supplies, and processors installed) Rated Line Voltage 90 to 140 VAC Input Requirements (per power supply) 180 to 264 VAC Rated Input Current 7.31A at 115VAC 3.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Technical Specifications Emissions Classification (EMC) HP iLO 4 On System Management Processor Architecture Processor Upgradeability Video Support Interfaces Memory Operating System Support Client System Support Client Browser Support DA - 14232 LWAd LpAm Operating LWAd LpAm FCC Rating Normative Standards 6.4 45dBA 6.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Technical Specifications version of Integrated Remote Console. Microsoft Internet Explorer 8 NOTE: For customers using Protected Mode, please use the Java based version of Integrated Remote Console. Microsoft Internet Explorer 7 Firefox Extended Support Release (ESR) 10 (on supported Windows and Linux systems Firefox 3.
QuickSpecs HP ProLiant SL250s Generation 8 (Gen8) Technical Specifications HP H220i Host Bus Adapter Disk Drive and Enclosure Interface - Transfer rate SAS Connectors Server Interface SAS Speed Cache Memory Physical Drives Supported Hot Plug Support RAID Support 6Gb/s SAS (Serial Attached SCSI) 6Gb/s SATA (Serial ATA) 2 internal 4X connectors x8 PCIe 3.0 provides 2GB/s maximum bandwidth 6Gb/s SAS links provide 4.
