Specifications

Category Description
Supports 3-mode diskette drive
Audio HD audio - ADI1981
Single speaker
Modem 56K V.92 1.5-inch data/fax modem with digital line guard
Modem cable included in the Czech Republic, Europe, France, Greece, Hungary, Israel,
Poland, Russia, Saudi Arabia, Slovakia, Slovenia, South Africa, Turkey, and the United
Kingdom
Ethernet Intel 82562GT
S3/S4/S5 wake-on-LAN: DC - no
S3/S4/S5 wake-on-LAN: AC - yes
Wireless Integrated WLAN options by way of wireless module:
2 WLAN antennae built into display assembly
Support for no-WLAN option
Support for the following WLAN formats:
●
Intel 802.11a/b/g/n without iAMT
●
Broadcom 802.11a/b/g
●
Intel 802.11a/b/g without iAMT
●
Intel 802.11a/b/g (not available on computer models equipped with Intel Celeron M
processors)
●
Broadcom 802.11b/g
●
Intel 802.11b/g (not available on computer models equipped with Intel Celeron M
processors)
Integrated personal area network (PAN) options by way of Bluetooth® module:
Support for no-WPAN option
Broadcom Bluetooth 2.0+EDR
External media card One ExpressCard/54 slot
SD/MMC Card Reader supporting Secure Digital (SD) Memory Card and MultiMediaCard
(MMC)
Ports Audio-in (mono microphone)
Audio-out (stereo headphone)
RJ-11 (modem)
RJ-45 (Ethernet, includes link and activity lights)
USB (3)
VGA (Dsub 15-pin) supporting 1600 × 1200 external resolution at 75-GHz (hot plug/unplug
with auto-detect)
2-pin AC power
Keyboard/pointing devices 14.45-inch keyboard with separate numeric keypad
3
