Spare part
number
Description
456586-001 Display enclosure (includes display bezel, 2 wireless antenna transceivers and cables)
456587-001 Keyboard for use in the United States
456587-031 Keyboard for use in the United Kingdom
456587-041 Keyboard for use in Germany
456587-051 Keyboard for use in France
456587-061 Keyboard for use in Italy
456587-071 Keyboard for use in Spain
456587-081 Keyboard for use in Denmark
456587-091 Keyboard for use in Norway
456587-121 Keyboard for use in French Canada
456587-131 Keyboard for use in Portugal
456587-141 Keyboard for use in Turkey
456587-171 Keyboard for use in Saudi Arabia
456587-181 Keyboard for use in Belgium
456587-211 Keyboard for use in Hungary
456587-221 Keyboard for use in the Czech Republic
456587-231 Keyboard for use in Slovakia
456587-251 Keyboard for use in Russia
456587-B31 Keyboard for use in the Netherlands
456587-B71 Keyboard for use in Sweden and Finland
456587-BA1 Keyboard for use in Slovenia
456587-BB1 Keyboard for use in Israel
456587-BG1 Keyboard for use in Switzerland
456587-DD1 Keyboard for use in Iceland
456587-DJ1 Keyboard for use in Greece
456601-001 TouchPad button board (includes cable)
456606-001 Heat sink (includes replacement thermal material)
456610-001 System board with 64-MB DDR1 graphics subsystem memory (includes replacement thermal material)
456611-001 System board with 128-MB DDR1 graphics subsystem memory (includes replacement thermal material)
456612-001 System board with 64-MB DDR2 graphics subsystem memory (includes replacement thermal material)
456613-001 System board with 128-MB DDR2 graphics subsystem memory (includes replacement thermal material)
456614-001 Plastics Kit (see Plastics Kit on page 18 for more Plastics Kit spare part information)
456615-001 Screw Kit
Sequential part number listing 25
