User's Manual

WLM200N5-26dBm MiniPCI network adapter provides leading 802.11a/n
performance
, supporting up to 300Mbps physical data rates and 200Mbps
of actual user throughput on both the uplink and downlink. Adding
Wireless N to your Wireless device, it provides higher efficiency for
everyday activities such as file transfers, Internet browsing, and media
streaming.
Compex WLM200N5-26dBm miniPCI network adapter offers
high output power of 400 mW, allowing an extended range of wireless
coverage. Combined with excellent receiver sensitivity, WLM200N5-
26dBm is the miniPCI choice for long distance links, or those where signal
levels are reduced due to minor obstructions such as trees or building.
Built on Atheros chipset, it can be used with all draft IEEE 802.11n
compatible WLANs, and is ideally suited to be integrated into a wide
range of OEM devices.
Features
•
5GHz IEEE 802.11a/n standard
•
Output Power of up to 26dBm @ a Band
•
Support for up to 2x2 MIMO with spatial multiplexing
•
Four times the throughput of 802.11a and 802.11n
•
Wireless Encryption and Authentication Supported
•
Transmission Power Control (TPC)
•
Enhanced performance with Atheros XSPAN technology Optimized for higher throughput
at long range
•
Hi
g
h Performance (up to 300Mbps physical data rates and 200Mbps of actual throu
g
hput)
with Low Power Consumption
•
Dynamic Frequency Selection (DFS)
•
Multi-Country Roaming Support (IEEE802.11d)
•
2 X MMCX Antenna Connector
•
Suitable for Embedded System or OEM Project
•
Affordable and Ideal for a Variety of Applications
WLM200N5-26MINIPCI
2 x 2 802.11N MIMO mini-PCI Modules
