After you collect the data, examine it for any changes in pattern, frequency, or amplitude.
The changes reveal how the equipment responds to these transient events or what causes
these events to occur.
7.1.2 Open or close the Advanced Transient program
1. To open the program, press F11 Adv. Transient on the Home screen.
2.
To close the program, press ALT > F7 Exit Transient.
7.1.3 Transient main menu
Note
Only the F8 Job Manager option is available if no Transient jobs were created or stored on the analyzer.
