Option Description
F12 Set Defaults Restore the default values for all tachometer setup options on the screen.
3. Press F6 Save / Recall Setup to save the setup, or press Enter to use the setup without
saving it.
7.4.2 Save a tachometer setup
The saved setup is accessible from all other programs on the analyzer.
Procedure
1.
From the Transient main menu, press ALT > F4 Tach Setup or F1 Setup / Acquire Data > F7
Tach Setup.
2. From the Tachometer Setup screen, press F6 Save / Recall Setup.
3. Use the up and down arrow keys to select Empty or another tachometer setup.
4. Press F2 Store Setup.
5. Enter up to 27 characters for the name.
6. Press Enter.
7.4.3 Open a saved tachometer setup
You can open and reuse a setup in any program on the analyzer.
Procedure
1.
From the Transient main menu, press ALT > F4 Tach Setup or F1 Setup / Acquire Data > F7
Tach Setup.
2. From the Tachometer Setup screen, press F6 Save / Recall Setup.
3. Use the up and down arrow keys to select a setup.
4. Press F3 Recall Setup.
The setup appears on the Tachometer Setup screen.
5. Press Enter.
7.4.4 Rename a saved tachometer setup
1. From the Transient main menu, press ALT > F4 Tach Setup or F1 Setup / Acquire Data > F7
Tach Setup.
2. From the Tachometer Setup screen, press F6 Save / Recall Setup.
3. Use the up and down arrow keys to select a saved setup.
4. Press F4 Edit Setup Desc.
5. Enter up to 27 characters for the name.
6. Press Enter.
Advanced Transient
