Procedure
1.
From the ODS/Modal main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F2 Edit Equip Desc.
4. Enter up to 28 characters.
5. Press Enter.
8.2.6 Activate an ODS/Modal job
Activating a job lets you collect data for that job. It is similar to opening a file. Activate a job
when you want to change jobs.
Procedure
1. From the ODS/Modal main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F3 Activate Job.
The ODS/Modal main menu displays the selected job.
8.2.7 Copy an ODS/Modal job
When you copy an existing job, the new job has a different job ID and no data.
Procedure
From the ODS/Modal main menu, press F8 Job Manager > F8 Copy Job.
The copy is saved as JobX, where X is a number.
8.2.8 Delete an ODS/Modal job
1. Press Home > F2 File Utility.
2.
Press F2 or F3 to scroll through the jobs. To change memory locations, press F10 Set
Source Card.
3. Press F9 Select/Unselect File to select the file to delete.
4. Press F7 Delete.
5. Press Enter.
