5. Press F3 Recall Setup.
Reset the acquisition parameters to default values
1.
From the ODS Analysis Setup screen, press F6 Save / Recall Setup.
2. Press F5 Recall Default Setup.
8.6.4 Save waveform data with ODS/Modal data
The time waveforms are not required for ODS/Modal jobs, but you can store them for
reference.
Procedure
1. Activate a job.
2. From the ODS/Modal main menu, press F8 Job Manager.
3. Use the up and down arrow keys to select a job.
4. Press F4 Edit This Job > F9 Save Waveforms.
8.6.5 Set the fixed reference sensor parameters
You cannot change these parameters after you collected data for the job.
Procedure
1. From the ODS/Modal main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F10 Set Fixed Reference Params.
4. Set the following options as necessary.
Option Description
F9 Set Fixed Ref
Input
Set the reference input to A, B, C, or D. Do not move the fixed reference
sensor during the job. The default is input A. If you disable the reference
input on the Input Setup screen, "???" displays next to the F9 Set Fixed Ref
Input key. For Modal jobs, the reference input is the input for the hammer.
F10 Set Fixed Ref
Point
Enter a value between 1 and the maximum number of points you entered.
This sets the measurement point of the fixed reference. The default is 1.
F11 Set Fixed Ref
Direction
Set the measurement direction (also referred to as the measurement
coordinate or measurement axis) of the fixed reference. The available
directions are dependent on the global coordinate system and directions
defined for the job. The default is X.
F12 Set Fixed Ref
Polarity
Set the direction for a measurement. The direction is usually determined
by the construction of the equipment. If you cannot place the sensor in
the positive direction, specify a negative direction. The default is Positive.
5. Press Enter.
ODS/Modal
176
