![](/manual/computational-systems/csi2140m1/user-s-manual-english/images/img-26.png)
Gestures
Up arrow (swipe up) Left arrow (swipe left)
Down arrow (swipe down)
2.8.7 Entering text
If a menu option lets you enter text, the screen lists a set of characters. Repeatedly press
the key or touchscreen until the desired character appears. Wait until the cursor moves
and then enter the next character.
2.8.8 Display Help
Use the Help key to access information about a menu option or key.
Procedure
1.
Press the Help key .
2.
Press a menu option.
The analyzer displays the Help text for that menu option.
3. Press Enter to close the Help text.
2.9 Settings
View and modify the default global settings from the Home ALT1 or ALT2 screens.
2.9.1 Enable or disable the beeper for key presses and status
indicators
You can enable or disable the beeper for status indicators or key presses.
Introduction to the analyzer
20
