The default is 3 seconds.
3.
Press Enter.
2.9.7 Set the time and date
The analyzer's time must be within 15 minutes of the computer's time for the analyzer and
computer to communicate successfully. If there is a time conflict, the analyzer prompts
you to automatically synchronize the analyzer with the computer's time.
Procedure
1. Press Home > ALT > F3 Set Time.
2. Set the following options.
Option Description
F2 Set Local Time Enter values for the time and date. Use the arrow keys to go to the
next value.
F5 Date Display Format Select the format used for the date.
F6 Time Display Format Select the 12 or 24 hour time format.
F9 Set Time Zone Select the time zone. If the time zone uses Daylight Savings Time, the
analyzer automatically adjusts the time and notifies you of the
change.
3. Press Enter.
2.9.8 Set the default display units
You can set the default display units for measurements and plots. You can also select
English, SI, or metric units, and the X and Y axis types for graphs.
Note
You can overwrite only the X and Y axes while in other programs.
Procedure
1.
Press Home > F4 Set Display Units.
2. Use the up and down arrow keys to select an option.
Option Description
F2 Set Accel Set the acceleration type. Not applicable for the Balance program.
The default is RMS.
F3 Set Veloc Set the velocity units. Not applicable for the Balance program. The
default is Peak.
Introduction to the analyzer
23
