File types and extensions
Note
The CSI 2140 uses different file extensions than the CSI 2130.
File extension File type
.ANJ Analyze or Advanced Analyze job
.BJB Balance job
.ODJ ODS/Modal job
.RDA Route Data File (created after a route is activated)
.RDF Route Definition File (an empty route file)
.TRJ Transient job
Copy a route or job file to a memory card or internal memory
1.
Insert a memory card into the analyzer.
2. Press Home > F2 File Utility.
3. Press F8 Mode until F7 displays Copy.
4. Press F10 Set Source Card to select the location of the file to copy.
The Source and Destination fields change.
5. Select the file to copy, and press F9 Select/Unselect File.
A checkmark appears next to the file.
6. Press F7 Copy.
The file appears at the new location.
Delete a route or job file from the memory card or internal
memory
Note
Use caution with the Delete option. Deleted data cannot be recovered.
Procedure
1.
Press Home > F2 File Utility.
2. Press F8 Mode until F7 displays Delete.
3. Press F10 Set Source Card and select the current location of the file, if a memory card
is inserted.
The Source field changes.
