![](/manual/computational-systems/csi2140m1/user-s-manual-english/images/img-61.png)
ALT1 keys
Option Description
F1 Prev Point Move to the previous measurement point on the equipment. If the first
point on the equipment displays and you press F1 Prev Point, the analyzer
displays the last point on the previous equipment.
F2 Prev Equip Move to the previous equipment in the route. If the first equipment
displays and you press F2 Prev Equip, the analyzer displays the last
equipment.
F3 Equip List View all equipment and measurement points in a route.
F4 Notes Create, add, or delete notes.
F5 Plot Data View the collected data on one or more plots.
F6 Listen To Live Data Listen to vibration using wireless headphones.
F7 Next Point Move to the next measurement point on the equipment. If the last point
on the equipment displays and you press F7 Next Point, the analyzer
displays the first point on the next equipment.
F8 Next Equip Move to the next equipment in the route. If the last equipment displays
and you press F8 Next Equip, the analyzer displays the first equipment.
F9 Start Acq Collect data for the measurement point. You can also press Enter to collect
data.
F10 Field Alert Add or remove a field alert from a measurement point. Use field alerts to
identify a point for further investigation.
F11 View Parms View the Analysis Parameter Set with measured values, percent of fault, and
any parameters that may be in alert.
F12 Run Analyze Open the Analyze program to collect additional data on the current
measurement point.
ALT2 keys
Option Description
F1 User Setup Set options for your route. You can set the plots to display live and
collected data, parameters to collect route data, and the amount of route
data to store.
F2 Override Control Set up a different sensor than what is specified for the route.
F3 Out Of Service Label equipment as out of service and skip the measurement.
F4 Intentionally blank.
F5 Tach Setup Set up and save a tachometer configuration. You can also open, edit,
delete, or rename a configuration.
F6 New RPM Enter a new RPM or load for equipment using a different value than
defined in the route.
F7 Exit Route Close Route and return to the Home screen.
F8 Clear Data Delete data from the current measurement point.
Route
55
DRAFT
