3. Select an Analysis Expert or mode in Manual Analyze to collect the desired type of data.
4.
Modify any data collection parameters in Manual Analyze. The data collection
parameters vary based on the selected Analysis Expert or Manual Analyze mode.
5. Collect the data.
6. View the plot.
7. Store the data to a job or route.
6.1.1 Open or close the Analyze program
1. To open Analyze, do one of the following:
• From the Route Data Collection screen, press F12 Run Analyze.
• From the Home screen, press F7 Analyze or F7 Adv. Analyze.
2. To close Analyze, press ALT > F7 Exit Analyze.
6.1.2 Analyze main menu
If you open Analyze from a route, the Analyze main menu looks different from the image
below. The screen will display the route name, equipment, the route area, and the
measurement point.
