Part Number MN/RAP100.IOM Revision 1

RAP-100

Remote Access Panel

Installation and O

eration Manual

Summary of content (34 pages)

PAGE 1
RAP-100 Remote Access Panel Installation and Operation Manual Part Number MN/RAP100.
PAGE 2
RAP-100 Remote Access Panel Installation and Operation Manual Comtech EFData is an ISO 9001 Registered Company. Part Number MN/RAP100.IOM Revision 1 December 8, 1999 Copyright © Comtech EFData, 2000. All rights reserved. Printed in the USA. Comtech EFData, 2114 West 7th Street, Tempe, Arizona 85281 USA, (480) 333-2200, FAX: (480) 333-2161.
PAGE 3
Errata A Comtech EF Data Documentation Update RAP-100 Remote Access Panel Installation and Operation Manual MN-RAP100.IOM REV 1 Original Manual Part Number/Rev: MN/RAP100.IOM Rev 1 Errata Number/ PLM Document ID: ER-RAP100-EA1 PLM CO Number: C‐0029408 Comments: The updated information will be in the next formal revision of the manual.
PAGE 4
ER-RAP100-EA1 Revision - This document is not subject to revision/update! PLM CO C-0029408 Page 2 of 2
PAGE 5
Customer Support Contact the Comtech EFData Customer Support Department for: • Product support or training • Information on upgrading or returning a product • Reporting comments or suggestions concerning manuals A Customer Support representative may be reached at: Comtech EFData Attention: Customer Support Department 2114 West 7th Street Tempe, Arizona 85281 USA (480) 333-2200 (Main Comtech EFData Number) (480) 333-4357 (Customer Support Desk) (480) 333-2161 FAX or, E-Mail can be sent to the Customer Suppor
PAGE 6
Table of Contents Customer Support....................................................................................................................................................... ii About this Manual .................................................................................................................................................... vii Conventions and References.............................................................................................................................
PAGE 7
Preface RAP-100 Remote Access Panel 3.2 MENU TREES................................................................................................................................. 3–2 3.2.1 SELECT .................................................................................................................................................. 3–2 3.2.2 ODU .......................................................................................................................................................
PAGE 8
RAP-100 Remote Access Panel Preface 3.2.26 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER,LNA) STATE (ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER,LNA) STATE (ODU,ENABLE,STANDALONE,CONFIG,RECEIVER,LNA) STATE..................................................................................................... 3–8 3.2.27 (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER,LNA) CAL (Calibrate) (ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER,LNA) CAL (Calibrate) (ODU,ENABLE,STANDALONE,CONFIG,RECEIVER,LNA) CAL (Calibrate)..........................
PAGE 9
Preface RAP-100 Remote Access Panel 3.2.48 (ODU,ENABLE,1:1,CSAT#1) ALARMS (ODU,ENABLE,1:1,CSAT#2) ALARMS (ODU,ENABLE,STAND-ALONE) ALARMS.................................................................................................. 3–13 3.2.49 (ODU,ENABLE,1:1,CSAT#1,ALARMS) CURRENT (ODU,ENABLE,1:1,CSAT#2,ALARMS) CURRENT (ODU,ENABLE,STAND-ALONE,ALARMS) CURRENT......................................................... 3–13 3.2.
PAGE 10
RAP-100 Remote Access Panel Preface About this Manual This manual provides installation and operation information for the Comtech EFData RAP-100 Remote Access Panel. This is a technical document intended for earth station engineers, technicians, and operators responsible for the operation and maintenance of the RAP-100. Conventions and References Cautions and Warnings CAUTION CAUTION indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
PAGE 11
Preface RAP-100 Remote Access Panel Warranty Policy This Comtech EFData product is warranted against defects in material and workmanship for a period of two years from the date of shipment. During the warranty period, Comtech EFData will, at its option, repair or replace products that prove to be defective. For equipment under warranty, the customer is responsible for freight to Comtech EFData and all related custom, taxes, tariffs, insurance, etc.
PAGE 12
1 Chapter 1. INTRODUCTION 1.1 Equipment Use: The RAP-100 is designed to provide front console monitoring and control of a single Comtech EFData CSAT Outdoor Transceiver. The RAP-100 is packaged in a chassis suitable for mounting in standard 19 inch Telecommunication equipment racks. 1.2 Equipment Power: The equipment is rated for operation over the range 100 – 240 volts AC. It has a maximum power consumption of 15 watts. 1.
PAGE 13
Introduction 1.4 RAP-100 Remote Access Panel Getting Started: After the interface cable between the RAP-100 and CSAT is built and installed, simple apply power for both units. The ‘Comm. Link’ LED on the front of the RAP-100 will be GREEN when the two units are communicating and RED when a problem exists. If the LED is RED go to the ‘LINK’ menu and select ‘ESTABLISH’. Select the when queried ‘RE-ESTABLISH COMM LINK?’.
PAGE 14
2 Chapter 2. REDUNDANT CSAT CONTROL The RAP-100 (Remote Access Panel) is designed to provide a simple ‘Indoor’ interface to Comtech EFData’s ‘Outdoor’ CSAT terminals. RAP-100’s with software version 1.03 (or later) installed also support direct communications with 2 CSATs and the Redundancy Controller Box in a redundancy configuration. The figure below provides a functional block diagram of a 1:1 Redundant CSAT system with a RAP-100 used as the system monitor and control device.
PAGE 15
Redundant CSAT Control RAP-100 Remote Access Panel There are a few important points to be made about this system architecture. First, the Redundancy Controller Box is in complete control of the transfer switches (both Tx and Rx) when the system is in AUTO mode. This means that the Redundancy Controller Box is always monitoring the status of both CSATs via their Summary Fault Relays and will change the position of the switches if the ONLINE unit fails.
PAGE 16
RAP-100 Remote Access Panel 2.1 Redundant CSAT Control RAP-100 Menus After connecting the RAP-100 to the Redundancy Controller Box and turning power ON for all of the components in the system the “COMM LINK” LED on the RAP-100 should be GREEN. If this LED is RED, verify that all interface cables between the two CSATs and the Redundancy Controller Box as well as the interface cable between the RAP-100 and the Redundancy Controller Box are properly made.
PAGE 17
Redundant CSAT Control 2.1.3 RAP-100 Remote Access Panel MODE Selection: This selection allows you to view and/or change the operating mode of the Redundancy Controller Box. If the cursor is on ‘AUTO’ the box is in Auto Mode. If the cursor is on ‘MANUAL’ the box is in Manual Mode. To change the operating mode, use the Right or Left Arrow keys to select the new mode then press the Enter key. (Note: you must always press the Enter key after making any change via any of the Arrow keys) 2.1.
PAGE 18
3 Chapter 3. ODU OPERATION 3.1 Front Panel ODU Operation The user can fully control and monitor the operation of Comtech EFData’s ODU from the front panel, using the keypad and display of either a CDM550 or CDM550T modem. Nested menus display all available options and prompt the user for required actions. The display has two lines each of 24 characters. On most menu screens, a flashing solid block cursor blinks once per second to indicate the currently selected item, digit, or field.
PAGE 19
ODU Operation RAP-100 Remote Access Panel 3.2 MENU TREES 3.2.1 SELECT SELECT: CONFIG TEST INFO MONIT STORE/LD UTIL ODU The user is presented with the following choices: CONFIG (Configuration) This menu branch permits the user to fully configure the unit. TEST This menu branch permits the user invoke one of several test modes (loopbacks, for example). INFO (Information) This menu branch permits the user to view information on the unit, without having to go into configuration screens.
PAGE 20
RAP-100 Remote Access Panel 3.2.4 (ODU,ENABLE) ODU Operation 1:1 MONITOR/CONTROL: CSAT#1 CSAT#2 RED BOX The user is prompted to select CSAT#1, CSAT#2 or the RED BOX as the device to be monitored. The first to selection will allow the user to monitor and/or control the configuration of the two individual ODU’s. The third item, RED BOX, will allow the user to monitor the current state of the ODU Redundancy Controller Box as well as to change the current ONLINE/OFFLINE state of each ODU. 3.2.
PAGE 21
ODU Operation 3.2.8 RAP-100 Remote Access Panel (ODU,ENABLE,1:1,RED BOX) SWITCHES WAVEGUIDE SWITCH STATUS: TX=OK RX=OK This menu item provides the status of both the Tx and Rx Waveguide transfer switches. If either switch is reporting an ambiguity from the commanded position the “OK” will change to “FT”. This indicates a switch fault. 3.2.9 (ODU,ENABLE,1:1,RED BOX) VOLTAGES REDUNDANCY BOX VOLTAGES: 5V= X.X 12V=XX.X This menu item provides monitor of the voltages inside the Redundancy Controller Box.
PAGE 22
RAP-100 Remote Access Panel 3.2.13 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) (ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) (ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) ODU Operation FREQUENCY FREQUENCY FREQUENCY EDIT ODU TX FREQUENCY: 5912.5 MHz (PRESS ENT) The user is prompted to edit the transmit frequency. This is accomplished by selecting the digit to be edited, using the LEFT/RIGHT arrow keys. The value of the digit is then changed using the UP/DOWN arrow keys. The user then press ENTER. 3.2.
PAGE 23
ODU Operation 3.2.17 RAP-100 Remote Access Panel (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) (ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) (ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) SLOPE SLOPE SLOPE SELECT TX SLOPE MODE: CALIBRATED MANUAL (ENT) The user is prompted to select either CALIBRATED or MANUAL, using the LEFT/RIGHT arrow keys, then to press ENTER. 3.2.
PAGE 24
RAP-100 Remote Access Panel 3.2.21 ODU Operation (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) ATTEN (Attenuation) (ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) ATTEN (Attenuation) (ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) ATTEN (Attenuation) EDIT ODU RX ATTENUATION: 15.00 dB (PRESS ENTER) The user is prompted to edit the receive attentuation. This is accomplished by selecting the digit to be edited, using the LEFT/RIGHT arrow keys. The value of the digit is then changed using the UP/DOWN arrow keys.
PAGE 25
ODU Operation 3.2.25 RAP-100 Remote Access Panel (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER) LNA (ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER) LNA (ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER) LNA SELECT LNA: STATE CAL CURR-WINDOW FAULT-LOGIC The user is prompted to select 1 of 4 selection using the LEFT/RIGHT arrow keys, then to press ENTER. 3.2.
PAGE 26
RAP-100 Remote Access Panel 3.2.29 ODU Operation (ODU,ENABLE,1:1,CSAT#1,CONFIG,RECEIVER,LNA) (ODU,ENABLE,1:1,CSAT#2,CONFIG,RECEIVER,LNA) (ODU,ENABLE,STAND-ALONE,CONFIG,RECEIVER,LNA) FAULT-LOGIC FAULT-LOGIC FAULT-LOGIC SELECT LNA FAULT LOGIC: SUMMARY NO SUMM (ENTER) The user is prompted to select either SUMMARY or NO SUMM, using the LEFT/RIGHT arrow keys, then to press ENTER. This controls whether or not the a LNA Current-Window fault will activate the SUMMARY FAULT RELAY.
PAGE 27
ODU Operation 3.2.33 RAP-100 Remote Access Panel (ODU,ENABLE,1:1,CSAT#1,CONFIG,MISCELLANEOUS) (ODU,ENABLE,1:1,CSAT#2,CONFIG,MISCELLANEOUS) (ODU,ENABLE,STAND-ALONE,CONFIG,MISCELLANEOUS) XREF(Ext Ref) XREF(Ext Ref) XREF(Ext Ref) SELECT EXT REFERENCE: YES NO (PRESS ENTER) The user is prompted to select either YES or NO, using the LEFT/RIGHT arrow keys, then to press ENTER. NOTE: The CSAT will automatically lock to an external 5 or 10 MHz reference independent of the state of this selection.
PAGE 28
RAP-100 Remote Access Panel 3.2.37 ODU Operation (ODU,ENABLE,1:1,CSAT#1,INFO) (ODU,ENABLE,1:1,CSAT#2,INFO) (ODU,ENABLE,STAND-ALONE,INFO) CSAT-5060/010 SERIAL # 00225 MODEL MODEL MODEL V2.09 (ENT) This window provides the CSAT Model Number and Serail Number, press ENTER. 3.2.38 (ODU,ENABLE,1:1,CSAT#1,INFO) (ODU,ENABLE,1:1,CSAT#2,INFO) (ODU,ENABLE,STAND-ALONE,INFO) Tx: ON AMP ON TRANSMITTER TRANSMITTER TRANSMITTER 5845.0 10.00 MUTE OFF 0.
PAGE 29
ODU Operation 3.2.42 RAP-100 Remote Access Panel (ODU,ENABLE,1:1,CSAT#1) (ODU,ENABLE,1:1,CSAT#2) (ODU,ENABLE,STAND-ALONE) MONITOR MONITOR MONITOR MONITOR: TX RX MISC PWR SUPP1 PWR SUPP2 The operator uses this menu item to select enter 1 of 5 ‘Monitor Windows’. Use the LEFT/RIGHT arrow keys, then press ENTER. 3.2.43 (ODU,ENABLE,1:1,CSAT#1,MONITOR) (ODU,ENABLE,1:1,CSAT#2,MONITOR) (ODU,ENABLE,STAND-ALONE,MONITOR) TX (Transmitter) TX (Transmitter) TX (Transmitter) TX: SYNTUNE=04.8 PWR=040 IFLO = 10.
PAGE 30
RAP-100 Remote Access Panel 3.2.47 ODU Operation (ODU,ENABLE,1:1,CSAT#1,MONITOR) (ODU,ENABLE,1:1,CSAT#2,MONITOR) (ODU,ENABLE,STAND-ALONE,MONITOR) PS: +5V=5.5 PWR SUPP2 PWR SUPP2 PWR SUPP2 -5V=-4.9 This window provides a monitor for the remaining two internal power supplies, press ENTER. 3.2.
PAGE 31
ODU Operation 3.2.51 RAP-100 Remote Access Panel (ODU,ENABLE,1:1,CSAT#1,ALARMS,STORED) (ODU,ENABLE,1:1,CSAT#2,ALARMS,STORED) (ODU,ENABLE,STAND-ALONE,ALARMS,STORED) VIEW VIEW VIEW LOG 02:11/13/99 10:42:47 OK- REF LOCK (UP/DWN) The operator uses the UP/DOWN arrow keys to sequentially view the individual entries in the Stored Events Log, then press CLEAR to exit the window. 3.2.
PAGE 32
