New Dock Items Float Section FS1120 1000 Series – Low Profile 90” x 120” x 10” (228.6 cm x 304.8 cm x 25.4 cm) Maximum flotation: 2800 lbs (1270 kg) per module Freeboard: 8” (20.32 cm) above the water Connect-A-Port 2XL 157” x 58.5” x 23” (398.8 cm x 148.6 cm x 58.4 cm) CAP0002 Longer PWC Docking and more rollers. 2000 Series Canopy Many sizes and color choices See page 25 Solar Light 3.36” x 1.68 x 7.73” (8.54 cm x 4.27 cm x 19.6 cm) SLD1020 Small Rectangle Dock Box 36” x 26” x 20” (91.
Table of Contents New Dock Items 1000 Series & 2000 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii PWC Docking Connect-A-Port 2XL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Connect-A-Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1000 Series - Low Profile (LP) Specifications & Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect-A-Port 2XL PWC Docking Connect to floating or fixed docks Keep your water fun on an “even keel” with Connect-A-Port 2XL! The Connect-A-Port 2XL is the PWC docking for you, universal hull support makes docking personal watercraft easier with the added length over the orginal Connect-A-Port and Stoltz Keel & more Bow rollers. Idle up to dock...roll off to launch. PWC Docking adds a safe harbor for your one-, two- or three-place personal watercraft.
Connect-A-Port 2XL PWC Docking Anchoring Floating Dock AKH2000 Optional: Longer attachment plate available Fixed Dock Attachment Kit AKF2001 2000 Series Attachment Kit AKS2000 * Connection kits also available in stainless steel Other Anchoring Options Floating Dock Bracket AKFFDB 4” x 4” Post Bracket AKF4X4 PWC Pole Bracket Sleeve AKFPSM * Connection kits also available in stainless steel Accessories PWC Side by Side Kit AKC2002 connectadock.
Connect-A-Port PWC Docking Attach to floating or fixed docks Connect-A-Port is the Personal Watercraft (PWC) dock with a universal hull support that makes docking your PWC easier. With the added length and Stoltz Keel & Bow rollers, you just idle up to the dock and roll back off to launch. Connect-A-Port provides a safe harbor for your one-, two- or even three-place personal watercraft.
Connect-A-Port PWC Docking Anchoring Floating Dock AKH2000 Optional: Longer attachment plate available Fixed Dock Attachment Kit AKF2001 2000 Series Attachment Kit AKS2000 * Connection kits also available in stainless steel Other Anchoring Options Floating Dock Bracket AKFFDB 4” x 4” Post Bracket AKF4X4 PWC Pole Bracket Sleeve AKFPSM * Connection kits also available in stainless steel Accessories PWC Side by Side Kit AKC2001 connectadock.
1000 Series - Low Profile (LP) SWIMMING, BOATING & FISHING A lifetime of waterfront adventures awaits with the family-friendly Connect-A-Dock floating dock system. Modular design and rugged construction allow a simple, quick and reliable way to build boat docks, rowing docks, fishing docks, swim platforms and anything else you can imagine at home, in parks and at resorts.
1000 Series - Low Profile (LP) • Modular design • 8” (20.32 cm) freeboard • Easy to install • Wood grain anti-skid surface • UV protected • Environmentally friendly • Salt water safe 1000 Series is the logical choice for extending your waterfront enjoyment providing the ultimate versatility in configuration, simple installation and extreme durability.
00 Series - Components 90” x 120” Float Section 45” x 60” Float Section 90” x 120” x 10” (228.6 cm x 304.8 cm x 25.4 cm) FS1120 The primary component of the slip fit connection system. Corner Float Section 45” x 60” x 10” (114.3 cm x 152.4 cm x 25.4 cm) FS1060 The primary component of the slip fit connection system. 44” x 33” x 10” (111.8 cm x 83.8 cm x 25.4 cm) CFS1010 Adds strength, stability and extra walking space to the fingers of your dock. Cleat 7” x 1.35” (17.78 cm x 3.
1000 Series - Components 3’ x 8’ Aluminum Gangway with Handrails 26” Guardrail 26” x 40” (66.04 cm x 101.6 cm) GR1026 (2 AC1000 Accessory Connectors and Hardware included) 3’ x 8’ x 3’ (91.4 cm x 243.8 cm x 91.4 cm) GWA3X8 3’ x 12’ Aluminum Gangway with Handrails 3’ x 12’ x 3’ (91.4 cm x 365.8 cm x 91.4 cm) GWA3X12 41” Guardrail 41” x 40” (104.14 cm x 101.6 cm) GR1041 (2 AC1000 Accessory Connectors and Hardware included) 3’ x 16’ Aluminum Gangway with Handrails 3’ x 16’ x 3’ (91.4 cm x 487.
1000 Series - Components Solar Light Swim Ladder 21” x 86” (53.34 cm x 218.44 cm) SL1000 Helps you get out of the water easily. Kayak Rack 3.36” x 1.68 x 7.73” (8.54 cm x 4.27 cm x 19.6 cm) SLD1020 Light up the dock edge at night. Self-Wicking Planter Edge Bumper Away With Geese 10” diameter x 11.625” (25.4 cm diameter x 29.5 cm) SWP1020 Enjoy your favorite flowers and plants. 10 2.5” x 3.5” x 8’ (6.35 cm x 8.89 cm x 243.84 cm) EB1020 Wheelchair edge bumper. 6’ x 18.25” (182.9 cm x 46.
1000 Series - Components Rectangle Dock Box 48.25” x 26.5” x 29” (122.6 cm x 67.31 cm x 73.7 cm) DBT8006 Extra heavy duty construction in our Dock Box with lockable reinforced cover. PowerHouse - Dock Box Corner 50” x 29.5” x 32.5” (127 cm x 74.93 cm x 82.55 cm) DBT8004 Plenty of storage space and a Newport Harbor Mate can be attached to the box. connectadock.com Dock Box Corner 48.25” x 28” x 30” (122.6 cm x 71.12 cm x 76.2 cm) DBT8000 Cover restrained with stainless steel cables.
1000 Series - Dock Packages (F, L, Swim Platform) 10’ 15’ (3.05 m) (4.57 m) 17’ 6” 6’ 20’ (6.10 m) 3’ 9” 7’ 6” 5’ (1.14 m) (2.29 m) (1.52 m) fpk1012 (1.83 m) 7’ 6” (2.29 m) 22’ 6” (6.86 m) 22’ 6” (6.86 m) 10’ (3.05 m) (5.33 m) fpk1014 fpk1013 10’ (3.05 m) 10’ 7’ 6” (2.29 m) (3.05 m) 8’ 9” 15’ (4.57 m) 18’ 9” (5.72 m) 22’ 6” (6.86 m) (2.67 m) 3’ 9” 3’ 9” 3’ 9” (1.14 m) (1.14 m) (1.14 m) lpk1011 lpk1012 lpk1014 11’ 3” (3.43 m) 10’ (3.
1000 Series - Dock Packages (T, Straight, U) 20’ (6.1 m) 3’ 9” 7’ 6” (2.29 m) (1.14 m) 10’ 3’ 9” 15’ (4.573 m) 13’ 9” (4.19 m) 18’ 9” (5.72 m) (3.05 m) 3’ 9” 15’ (1.14 m) (1.14 m) (4.57 m) tpk1012 tpk1013 tpk1015 5’ (1.52 m) 7’ 6” (2.29 m) 3’ 9” 26’ 3” (8.00 m) (1.14 m) 15’ 20’ (4.57 m) (6.1 m) spk1013 15’ 15’ (4.57 m) (4.57 m) 13’ 9” upk1011 (3.43 m) (2.29 m) (4.19 m) 15’ 11’ 3” 7’ 6” 7’ 6” (2.29 m) (4.57 m) spk1016 spk1015 18’ 9” 15’ (5.72 m) (4.
2000 Series - High Profile (HP) HOME & COMMERCIAL DOCKS A season’s worth of adventures awaits with your floating dock, including parties, sunbathing, swimming, fishing and boating. A Connect-A-Dock system will prove to be a worthwhile addition to the value of your property. Commercial applications use the 2000 SERIES - (HP) dock because of its modularity.
2000 Series - High Profile (HP) • Modular design • 17” (43.18 cm) freeboard • Easy to install • Wood grain anti-skid surface • UV protected • Environmentally friendly • Salt water safe Connect-A-Port PWC Drive On adds a safe harbor for your one-, two- or three-place personal watercraft! Docking is easy with the unique bow stop. Launching is a breeze with the keel and bow rollers — just roll off and you are ready to go! 2000 Series creates a substantial and attractive pres- ence on the waterfront.
2000 Series - Components 72” x 120” Float Section 48” x 96” Float Section 72” x 120” x 20” (182.9 cm x 304.8 cm x 51 cm) FS2120 The primary component of the easy slip fit connection system. Corner Float Section 48” x 67” x 20” (121.9 cm x 170.1 cm x 50.8 cm) CFS2022 Adds strength, stability and extra walking space to the fingers of your dock. 16 48” x 96” x 20” (122 cm x 244 cm x 51 cm) FS2096 The primary component of the easy slip fit connection system. 2’ x 4’ Float Section 24” x 48” x 20” (60.
2000 Series - Components Connect-A-Port 2XL Connect-A-Port 157” x 58.5” x 23” (398.8 cm x 148.6 cm x 58.4 cm) CAP0002 2000 Series Attachment Kit AKS2000 PWC Side by Side Kit AKC2002 Longer PWC Docking and more rollers. 151” x 59” x 26.5” (383.5 cm x 149.9 cm x 67.3 cm) CAP0001 2000 Series Attachment Kit AKS2000 PWC Side by Side Kit AKC2001 12” x 9” x 20” (30.48 cm x 22.86 cm x 50.8 cm) FC2020 Slip fits into the Float Section sockets to hold the sections together. connectadock.
00 Series - Components Gangway 4’ x 4’ 49.96”x 53.7” (126.9 cm x 136.4 cm) GW1024 Gangway 6’ x 8’ 72.5”x 96” (184.15 cm x 243.84 cm) GW1036 Gangway Hinge 44” (Shown) 44” x 4” (118.8 cm x 10.16 cm) GH2010 Gangway 4’ x 8’ (shown) Gangway Hinge 54” Gangway 4’ x 12’ Gangway Hinge 56” 49.96”x 98.8” (126.9 cm x 250.95 cm) GW1028 49.96”x 144” (126.9 cm x 365.76 cm) GW1032 Lightweight frame with slip resistant panels. 18 54” x 8” (137.16 cm x 20.32 cm) GHGW5 56” x 6.94” (142.24 cm x 17.
2000 Series - Components 3’ x 8’ Aluminum Gangway with Handrails 4’ x 8’ Aluminum Gangway with Handrails (Shown) 3’ x 8’ x 3’ (91.4 cm x 243.8 cm x 91.4 cm) GWA3X8 4’ x 8’ x 3’ (121.9 cm x 243.8 cm x 91.4 cm) GWA4X8 3’ x 12’ Aluminum Gangway with Handrails 4’ x 12’ Aluminum Gangway with Handrails 3’ x 12’ x 3’ (91.4 cm x 365.8 cm x 91.4 cm) GWA3X12 4’ x 12’ x 3’ (121.9 cm x 365.8 cm x 91.
2000 Series - Components Utility Channel - Straight 49.56” x 24” x 20” (125.88 cm x 60.96 cm x 50.8 cm) UT2048 Utility Channel - Corner 47.91” x 47.91” x 20” (121.7 cm x 121.7 cm x 50.8 cm) UTC2048 Utility Channel - Cube 23.81” x 24” x 20” (60.47 cm x 60.96 cm x 50.8 cm) UT2024 Add water, electrical or sewer conduit lines. 2000 Series Hatteras Utility Pedestal 31”x 13.5”x 15.5” 78.74 cm x 34.29 cm x 39.37 cm HU2000 Add water, electrical lines 20 Firehouse 43.5”x 9.875”x 9.875” 110.49 cm x 25.
2000 Series - Components Swim Ladder Flag Pole 21” x 86” (53.34 cm x 218.44 cm) SL2000 Helps you get out of the water easily Cleat 7” x 1.35” (17.78 cm x 3.43 cm) 8C1020 A strong, secure tie off for your mooring lines. FP2000 Pole Bracket PB2020 Accessory Connector-Metal AC2022MTL Telescoping Flag Pole - 10’, 15’ or 20’. Extra Flotation 48” x 24” x 14” (122 cm x 60.96 cm x 35.5 cm) EF2020 Slips under your dock to provide extra lift where needed. connectadock.com Accessory Connector 5.75” x 19.
2000 Series - Components 2000 Series Bench 48” x 22” x 38.5” (121.92 cm x 55.88 cm x 97.79 cm) BH2000 Take time to sit back and enjoy life on your bench! Edge Bumper 2.5” x 3.5” x 8’ (6.35 cm x 8.89 cm x 243.84 cm) EB1020 Wheelchair edge bumper. Kayak Rack 6’ x 18.25” (182.9 cm x 46.36 cm) KR1020 Store two Kayaks on your dock. Self-Wicking Planter 10” diameter x 11.625” (25.4 cm diameter x 29.5 cm) SWP1020 Enjoy your favorite flowers and plants while you relax on your dock.
2000 Series - Components Rectangle Dock Box 48.25” x 26.5” x 29” (122.6 cm x 67.31 cm x 73.7 cm) DBT8006 Extra heavy duty construction in our Dock Box with lockable reinforced cover. PowerHouse - Dock Box Corner 50” x 29.5” x 32.5” (127 cm x 74.93 cm x 82.55 cm) DBT8004 Plenty of storage space and a Newport Harbor Mate can be attached to the box. connectadock.com Dock Box Corner 48.25” x 28” x 30” (122.6 cm x 71.12 cm x 76.2 cm) DBT8000 Cover restrained with stainless steel cables.
44” Guardrail 44” x 40” (111.76 cm x 101.6 cm) GR2044 Color: brown or white (2 AC2000 Accessory Connectors and Hardware included) 67” Guardrail 67” x 40” (170.18 cm x 101.6 cm) GR2067 Color: brown or white (2 AC2000 Accessory Connectors and Hardware included) Solar Light 3.36” x 1.68 x 7.73” (8.54 cm x 4.27 cm x 19.6 cm) SLD1020 Light up the dock edge at night. 92” Guardrail 92” x 40” (233.68 cm x 101.
We’ve Got You Covered... Protect your floating boat slip with a Genuine canopy frame and cover. This new kit will allow most ShoreStation model canopy frames to be attached directly to a Connect-A-Dock 2000 Series–High Profile Floating Dock, protecting your boat from the elements. The sturdy aluminum framework will not rust and adds stability to your floating dock.
2000 Series - Dock Packages (F, L, Deck) 22’ (3.05 m) (1.22 m) (6.71 m) 4’ 20’ 24’ (6.10 m) 6’ 10’ 4’ (3.05 m) (1.22 m) 24’ (7.32 m) (7.32 m) 30’ (9.14 m) 10’ 10’ 4’ (3.05 m) (1.22 m) 24’ (7.32 m) 4’ (1.83 m) 8’ (1.22 m) fpk2013 (2.44 m) fpk2015 fpk2014 12’ (3.66 m) 20’ (6.1 m) 14’ 16’ (4.88 m) 30’ (9.14 m) 32’ (9.75 m) (4.27 m) 4’ 4’ 4’ (1.22 m) (1.22 m) (1.22 m) lpk2014 lpk2013 lpk2015 16’ (4.88 m) 18’ (5.49 m) 12’ dpk2008 dpk2009 10’ (3.
2000 Series - Dock Packages (T, Straight, U) 20’ 36’ (6.1 m) 16’ (10.97 m) (6.10 m) 20’ 16’ 16’ (4.88 m) (4.88 m) 6’ (1.83 m) (4.88 m) 4’ 4’ 4’ (1.22 m) tpk2012 (1.22 m) tpk2013 tpk2014 16’ (4.88 m) 20’ 24’ (6.1 m) (7.32 m) (1.22 m) 4’ 6’ (1.22 m) 4’ (1.83 m) spk2010 (1.22 m) spk2011 spk2012 10’ (3.05 m) 10’ (3.05 m) 8’ 16’ (4.88 m) 24’ (7.32 m) 28’ (8.53 m) (2.44 m) 16’ upk2015 18’ 18’ (4.88 m) (5.49 m) (5.
Anchoring Stiff Arm Note: Dock anchoring methods listed in this book are only suggestions. It is up to you to determine which method suits your needs. Unless stated, anchoring items can be used for both 1000 SERIES (LP) & 2000 SERIES (HP) dock systems. Sea Tech Anchor Boat anchoring SK 1600 Jet Ski Mooring Stiff Arm Fittings 2” (5.08 cm) Id pole SAF1020 Connects a pole to the permanent land fitting and the Stiff Arm Bracket. Pole Pounder 2” & 3” pipe (5.08 cm & 7.
Anchoring Gangway Roller Kit 2” x 10.5” x 3” (5.08 cm x 26.67 cm x 7.62 cm) RK1020 - (sold in pairs) Allows gangway to roll on the dock in fluctuating waters. Gangway Hinge 44” 44” x 4” x 1/8” (111.8 cm x 10.16 cm x 0.32 cm) GH2010 Enables connection from gangway to dock and allows the gangway to fold 180˚ (wood plank not included). Piling Loop PL1012 14” (35.56 cm) PL1014 PL1010 Lets your dock ride on the pilings of a pier or other piling structures. Perfect for fluctuating waters. connectadock.
Technical Specifications 1000 Series - Low Profile (LP) Model Size 45” x 30” Float Section FS1030 30” x 45” x 10” (76.2 cm x 114.3 cm x 25.4 cm) 50 lbs (22.68 kg) 9.375 ft 2 (0.871 m 2) 45” x 60” Float Section FS1060 60” x 45” x 10” (152.4 cm x 114.3 cm x 25.4 cm) 86 lbs (39 kg) 18.75 ft 2 (1.74 m 2) 90” x 120” Float Section 44” x 33” Corner Float Section FS1120 CFS1010 90” x 120” x 10” (228.6 cm x 304.8 cm x 25.4 cm) 44” x 33” x 10” (111.8 cm x 83.8 cm x 25.4 cm) ft 2 (22.
Connect-A-Port 2XL CAP0002 157" x 58.5" x 23" (398.8 cm x 148.6 cm x 58.4 cm) 340 lbs (154.2 kg) 1700 lbs (771 kg) Utility Channel - Straight Attaches to 2000 Series and fixed docks. Multiple units can be linked CAP0001 151” x 59” x 26.5” (383.5 cm x 149.9 cm x 67.3 cm) 333 lbs (151 kg) Attaches to 2000 Series and fixed docks. Multiple units can be linked UT2048 49.56” x 24” x 20” (125.88 cm x 60.96 cm x 50.8 cm) 79.5 lbs (36 kg) 8 ft 2 (0.
Installation & Warranties & Patents It’s Easy and Fast to Install Assembly only takes a few hours! You don’t have to get into the water! The Connect-A-Dock floating dock modules are easy to connect to each other using only a few bolts in just minutes. The only tool you need is a 9/16th” (16 mm) socket wrench. Time is precious — we believe you should be spending time enjoying your dock — not assembling it! CONNECT-A-DOCK® Warranty - U.S.A.
Dock Applications connectadock.
Connect-A-Dock 1501 Owner Avenue Atlantic, IA 50022 USA
