ContaminationSensor CS 1000 Technical data
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 102/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
Technical data
General data
Mounting position Any (recommended: vertical position)
Self-diagnosis
continuously with error indication via status LED
and display
Display (only CS 1x2x) LED, 6 digits, in 17 segment format
CS 12xx ISO / SAE Measured variables
CS 13xx ISO / SAE / NAS
Flow ml/min
Out mA or VDC depending on model
Drive %
Service variables
Temp °C and °F
Ambient temperature range -30 … 80 °C / -22 … 176 °F
Storage temperature range -40 … 80 °C / -40 … 176 °F
Relative humidity max. 95%, non-condensing
CS 1xx0 FKM Material of seals
CS 1xx1 EPDM
Protection class III (safety extra-low voltage)
IP class IP 67
Weight ~ 1,3 kg
Hydraulic data
Operating pressure maximum 350 bar / 5075 psi
Hydraulic connection
- Pipe/hose connection Thread G ¼ according to ISO 228
- Flange connection DN 4
Permitted measurement flow rate 30 … 500 ml/min
Permissible viscosity range 1 … 1000 mm²/s
Fluid temperature range 0 …80 °C / 32 …185 °F
Electrical data
Connection plug M12x1, 8 pole, specified in DIN VDE 0627
Supply voltage
9 … 36 V DC, residual ripple < 10%, (protected
against polarity reversal)
Power consumption 3 W max.
Analogue output
2-conductor technology
4 … 20 mA active output
(max. burden 330Ω)
or
2 … 10 V active output
(minimum load resistance 820 Ω)
Switching output
passive, n-switching Power MOSFET:
maximum switching current 2 A,
maximum switching voltage 30 V DC,
dead open
