ContaminationSensor CS 1000 Operating the CS1x2x using the keypad
HYDAC FILTER SYSTEMS GMBH
en(us)
Page 37/112
BeWa CS1000 3764916 300 en-us 2012-08-29.doc 2012-08-29
CALIB
Select calibration
(only 13xx)
FREEZE
Set history memory
DFAULT
Reset CS to factory default
settings
CANCEL
Discard changes and exit
SAVE
Save changes and exit
CODE
For internal use only
MODE
Select measurement
mode
+
Code
M1
Continuous measurement
M2
Continuous measurement and
switching
M3
Filter to cleanliness class and
stop
M4
Filter with continuous
monitoring
SINGLE
Single measurement
mTIME
Set measuring
duration
+
Code
60
Set measuring duration
(10 ... 300 seconds)
