Installation manual

APPENDIX 4
Specification
Models CS1000-20 Stand Alone and CS1001-20 Plug On
Dimension (h x w x d) 125 x 172 x 62 mm
Weight 800 grams (includes internal battery)
Mounting Any orientation.
Temperature -20C to +60C transit, -4C to +50C operating
Humidity 0 - 80% non-condensing
Warranty 2 years
Telephone Path PSTN technology. CTR21 approved.
Ringer Equiv. No. (REN) 1.0
Radio Path Vodafone Data Network (VDN)
Battery CS0380, 12 volt, 800mA/h Lead-acid gel
Battery Life 2 hours minimum from fully charged.
Abort Facility Built In, selectable by programming
Power Requirement 12.0 - 15.0 volts DC, 0.1volt max ripple
Current Consumption 230mA quiescent + internal battery charge current
1A (totally flat internal battery being recharged)
Hourly battery test Internal battery and external supply.
Low Battery 10.8-11.0 volts falling, 11.8-12.0v recovery
Inputs 8 expandable to 16 inputs using CS1050
Outputs CS1000, 2 changeover relays (24v 1A contacts)
CS1001, 5 volt logic levels
8 additional transistor outputs using CS1050
Start Inputs Max +15 volt, Min 0 volts DC
Security Reference:
NATM9 NACOSS Guidelines for installing Paknet.
Regulatory Requirements
Before attempting to install Dualcom, the installer must be aware that the CS1000
range of Dualcom products may only be installed by a professional installer.
The Ringer Equivalence Number (REN) of the apparatus is 1.0. The sum of
RENs of the individual items connected to one PSTN line should not exceed 4.
