Datasheet

209023
940207
601007
940210
940411
940407
601008
940410
Diese Daten sind Richtwerte. Änderungen behalten wir uns vor.
Wire & Cable Specification (RG6 /U)
Type RG6U Coaxial Cable
Application High Frequency Signal Transmission
Description
Φ1.10mm CCS +Φ5.0mm FOAM PE + 0.05mm Double Al Foil + 7x16x0.12mm Al-Mg wires 75% coverage
braiding +Φ6.8mm PVC sheath, halogen free
Conductor 1.10+/-0.01 CCS
Material : Foam Polythene
Dielectric
Nom. O.D 5.0+/-0.1mm
Shealth 1 18mm Width 0.05mm Thickness Double Aluminum Foil
Braiding 2 7 x 16 x 0.12 Aluminum-My Alloy Wire Braiding 75% Coverage
Material : ROHS PVC / Color : Black or White
Sheath
Nom. O.D 6.8+/-0.1mm
Nominal Impedance : 75+/-3Ω
Nom. Capacitance: 53 pF/m
Screening Factor: >90dB
Maximum Operating Volts: 2700 V RMS
Nominal Velocity of Propogation : 82%
MHz 50 100 200 400 800 1000 1800 2150 2400
Electrical Properties
Max. Att
(dB/100m)
dB 4.1 5.1 7.4 12.0 18.1 19.7 25.9 30.0 32.5
