Data Sheet

10
2002-2003
Normal Size
CFR0W8 CFR-12 1/8W 1.85 3.5 0.5 28 200V 400V 400V 1Ω ~ 1MΩ
CFR0W4 CFR-25 1/4W 2.5 6.8 0.6 28 250V 500V 500V 1Ω ~ 10MΩ
CFR0W2 CFR-50 1/2W 3.5 10 0.6 28 350V 700V 700V 1Ω ~ 10MΩ
CFR01W CFR-100 1W 5.5 16 0.8 28 500V 1000V 1000V 1Ω ~ 10MΩ
CFR02W CFR-200 2W 6.5 17.5 0.8 28 500V 1000V 1000V 1Ω ~ 10MΩ
Small Size & Extra Small Size
CFR0S4 CFR-25-S 1/4W 1.85 3.5 0.5 28 200V 400V 400V 1Ω ~ 1MΩ
CFR0U2 CFR-50-SS 1/2W 2.5 6.8 0.6 28 250V 500V 250V 1Ω ~ 10MΩ
CFR0S2 CFR-50-S 1/2W 3 9 0.6 28 350V 700V 700V 1Ω ~ 10MΩ
CFR01S CFR-100-S 1W 5 12 0.7 28 500V 1000V 1000V 1Ω ~ 10MΩ
CFR02S CFR-200-S 2W 5.5 16 0.8 28 500V 1000V 1000V 1Ω ~ 10MΩ
CFR03S CFR-300-S 3W 6.5 17.5 0.8 28 500V 1000V 1000V 1Ω ~ 10MΩ
+0.02
- 0.05
Power Dimension (mm) Max. Max. Dielectric
Part No. Type Rating At
DL
dH ± 3
Working Overload Withstanding
Resistance
70°C Max. Max. Voltage Voltage Voltage
Range
Carbon Film Fixed Resistors:
 High quality performance
 Great economy
 Flame retardant type available
 Automatically insertable
Feature
Specifications
 Standard E-24 series values in ± 5% tolerance
 Standard Beige base color; Special Lavender base color for CFR01S, CFR02S & CFR03S
 Standard Grayish-green base color (Non-Flammable coating) for CFR0U2 (CFR-50-SS)
 For any special inquiry which including too low or high ohmic values is available on a case to case basis
Ambient temperature (
°
C)
Nominal resistance (
99
99
9)
Nominal resistance (
99
99
9)
Derating Curve Current Noise Level Temperature Coefficient
