User guide
Table Of Contents
- IMPORTANT SAFETY INSTRUCTIONS
- Important Installation Instructions Ds4020/Ds 4020H/Ds & 4020HX (only)Gate operation
- Pad and Operator Location
- Important Installation Instructions for the DST 4520 0nly
- Gate operation
- Pad and Operator Location
- Concrete Pad Construction and Layout
- Operator Mounting
- Universal gate arm Installation Guidelines
- Arm Installation
- Initial Limit Adjustment
- Pipe Connection
- Dorene DGC2000 Controller
- Power Connection / Electrical Hookup115 Volt Single PhaseSee figure 10
- Mag-Lock installationIf a 115 volt lock is used, connect the neutral wire from the lock to port #7 and the power wire from thelock to port #6
- Final Limit Adjustment
- DGC – 2000 Controller Settings
- Hand
- Close Timer
- Reverse Delay
- Close Delay
- Motor Run Timer
- Sensitivity Adjustment
- Warning Alarm
- To Hold Gate Open
- JP-3
- Led enable switch
- Final Assembly
- Blue Box formatAll Commands are dry contact, except JS4 & JS8
- JS1
- JS2
- JS3
- JS4
- JS5
- JS6
- JS7
- JS8
- JS9
- JS10
- Jp3
- Jp4
- Shadow loop Installation
- SychronousOPEN/CLOSE OPERATIONDGC 2000
- Double Swing gate loop placement
-
- Final Check
- Maintenance
- Safety Accessories
- Installation
- Testing
- Warning
- Caution
- Troubleshooting
- The left LED’S
- The Right LED’s
- Gate will not open or operate
3
GENERAL SAFETY INFORMATION
READ THROUGH THE INSTALLATION INSTRUCTIONS COMPLETELY BEFORE
BEGINNING INSTALLATION, AND THEN PERFORM THEM IN THE ORDER GIVEN
IMPORTANT SAFETY INSTRUCTIONS
Warning: To reduce the risk of injury or death
Read and follow all instruction carefully.1.
Never let children operate or play with gate controls. Keep the remote control away from children.2.
Always keep people and objects away from the gate. No one should cross the path of a moving gate.3.
Test the gate operator monthly. e gate MUST reverse on contact with a rigid object or stop when an 4.
object activates the non-contact sensors. Aer adjusting the force or the limit of travel, retest the gate
operator. Failure to adjust and retest the gate operator properly can increase the risk of injury or death.
Use the emergency release only when the gate is not moving.5.
Keep gate properly maintained. Read the owner’s manual. Have a qualied service person make 6.
repairs to gate hardware.
e entrance is for vehicles only. Pedestrians must use separate entrance.7.
Save these instructions.8.
FOR GATE OPERATORS UTILIZING A NON-CONTACT SENSOR
See Manufacturers instructions on the placement of non-contact sensors for each type of application.1.
Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle, trips the sensor 2.
while the gate is still moving.
One or more non-contact sensors shall be located where the risk of entrapment or obstruction exists, 3.
such as the perimeter reachable by a moving gate or barrier.
FOR GATE OPERATORS UTILIZING A CONTACT SENSOR
One or more contact sensors shall be located at the leading edge, trailing edge, and post mounted both 1.
inside and outside of a vehicular horizontal slide gate.
A hard wired contact sensor shall be located, and it’s wiring arranged, so that the communication between 2.
the sensor and the gate operator is not subjected to mechanical damage.
A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for 3.
entrapment protection functions shall be located where the transmission of the signals are not obstructed or
impeded by building structures, natural landscaping or similar obstruction. A wireless contact sensor shall
function under the intended end-use conditions.
