Model 5i Digital Force / Torque Indicator User’s Guide

Thank you…

Thank you for purchasing a Mark-10 Model 5i digital force / torque indicator,

designed for use with interchangeable remote force and torque sensors. A 5i-

sensor combination can be used with some Mark-10 test stands grips, and

data collection software.

With proper usage, we are confident that you will get many years of great

service with this product. Mark-10 instruments are ruggedly built for many

years of service in laboratory and industrial environments.

This User’s Guide provides setup, safety, and operation instructions.

Dimensions and specifications are also provided. For additional information or

answers to your questions, please do not hesitate to contact us. Our technical

support and engineering teams are eager to assist you.

Before use, each person who is to use a Model 5i indicator should be

fully trained in appropriate operation and safety procedures.

TABLE OF CONTENTS

OVERVIEW .........................................................2

POWER ...............................................................4

MECHANICAL SETUP .......................................5

HOME SCREEN AND CONTROLS ...................7

OPERATING MODES .........................................9

DIGITAL FILTERS ............................................11

SET POINTS .....................................................12

DATA MEMORY AND STATISTICS ................13

COMMUNICATIONS ........................................14

CALIBRATION .................................................21

PASSWORDS ...................................................25

OTHER SETTINGS ...........................................27

SPECIFICATIONS ............................................30
