Specification

W
G
•
Heavy gauge galvanized steel mounting strap for
corrosion resistance
•
For use with copper or aluminum wire
•
Flush receptacles fit one-gang or two-gang
enclosures
•
Surface receptacles have patented lay-in termi-
nals that accept up to #4 AWG wire
•
Surface receptacle backs feature concentric
knockouts and an adjustable cord clamp to allow
wiring from back or bottom
Flush power NEMA TT
Rating
A V/AC Description Color Catalog no.
30 125 NEMA TT-30R flush mount power receptacle, matching plug 83 BK 1263 •
Listed to UL498, file no. E15058; CSA certified to CSA C22.2, no. 42
Flush power NEMA 5-30R & NEMA 6-30R
Rating
A V/AC Description Color Catalog no.
30 125 NEMA 5-30R flush mount power receptacle, matching plug S41 BK 1233 •
30 250 NEMA 6-30R flush mount power receptacle, matching plug S42 BK 1234 •
Listed to UL498, file no. E15058; CSA certified to C22.2, no. 42; NOM certified
Surface power receptacle
Rating
A V/AC Description Color Catalog no.
30 250 NEMA 6-30R surface mount power receptacle, matching plug S42 BK 1232 •
Listed to UL498, file no. E15058; CSA certified to C22.2, no. 42; NOM certified
Panel power receptacles
Rating
A V/AC Description Color Catalog no.
30 125 NEMA TT-30R panel mount power receptacle, matching plug 83 BK U1263 •
Listed to UL498, file no. E15058; CSA certified to C22.2, no. 42; NOM certified
Product description
2-pole, 3-wire grounding
30A,125V/AC
30A, 250V/AC
Design features
Heavy duty grade power receptacles
Power devices
BK
(Black)
Color ordering information:
BK (Black)
Dimensional information: B-70 Specification information: Please visit www.cooperwiringdevices.com
Compliances, specifications and availability are subject to change without notice.
Indicates NAFTA compliant - Page F-21
1263
1232
U1263
B
SECTION
