GB Before installing and using the appliance read this user's instruction book carefully. It contains safety precautions, hints, information and ideas. If the refrigerator is used in compliance with the instructions written, it will operate properly and provide you with greatest satisfaction. The symbols below help you to find things more easily: Safety precautions Warnings and information at this symbol serve safety for you and your appliance.
GB Cont ents Important safety information ..................................................................................................22 General safety precautions....................................................................................................22 Precautions for child safety....................................................................................................22 Safety precautions for installation ........................................................................
GB Im por t ant saf e t y inf or mation General safety precautions Precautions for child safety Keep these instructions and they should remain at the appliance when moving away or changing owner. Do not allow children to play with the packaging of the appliance. Plastic foil can cause suffocation. This appliance is designed for storing food, domestic use according to these instructions only. Adults must handle the appliance. Do not allow children to play with it or its controlling parts.
GB Ins tr uctions f or the User General information quantity given in the user's instructions at home and making ice. The official designation of the appliance is 'refrigerator-freezer combination with one motor compressor and freezer placed in the lower part'. The appliance has -besides the general services- a freezer with its own door and is completely separated from the other unit.
GB Indicating switch To use the yellow indicating switch placed in the cover frame can be necessary in two cases: 1. Push the switch (it will move outwards and the indicator lamp will give light) when the ambient temperature goes beyond +16 °C. The switch operates a heater, which ensures that the necessary -18 °C storing temperature can be used. This is effective to an ambient temperature limit of +10 °C. 2. To reach higher freezing capacity from 3 kg/24h, 12 kg/24h to 18 kg/24h see chapter Freezing.
GB How to use the refrigerator For adequate cooling developing interior air circulation is necessary. For this reason you are asked not to cover the whole surface of the wire shelves with paper, trays, etc. Do not put hot food into the refrigerator. Allow it to reach room temperature naturally. In this way the unnecessary frost building up can be avoided. Foods can take over odours from each other.
GB How to use the freezer Freezing different products should always be done in the freezing compartment or rather on its cooling plate after proper preparing. It is safe to store quick-frozen, frozen foods only if they have not dissolved even for a short time until placing them into the freezer. If the deepfrozen food has already dissolved, refreezing is not recommended, it has to be used up as soon as possible.
GB Hints and ideas Maintenance In this chapter practical hints and ideas are given about how to use the appliance to reach maximum energy saving and there is environmental information about the appliance as well. Defrosting How to save energy Avoid putting the appliance in a sunny place and near anything that gives off heat. Be sure that the condenser and the compressor are well ventilated. Do not cover the sections where ventilation is.
GB In case of increased demand e.g. during heatwaves, the refrigerator temporarily happens to operate constantly during this the automatic defrosting is ineffective. Remaining small ice and frost stains on back plate of the refrigerator after defrosting period is not abnormal. The freezer can not be equipped with automatic defrosting set since the deep-frozen and frozen foods do not endure melting temperature.
GB Regular cleaning It is recommended to wash the inside of the refrigerator in 3-4 weeks time using lukewarm water then wipe it (it is practical to clean the inside of the freezer and defrost it at a time). Household cleaner or soap must not be used. After breaking the circuit wash the appliance with lukewarm water then wipe it. Clean the door gasket with clean water. After cleaning apply voltage to the appliance.
GB Problem Possible cause It is too warm in the Thermostatic control can be set wrongly. refrigerator. If products are not cold enough or placed wrongly. The door does not close tightly or it is not shut properly. It is too warm in the Thermostatic control can be set wrongly. freezer. The door does not close tightly or it is not shut properly. Products in big quantity to be frozen were put in. Products to be frozen are placed too closely to each other. Water flows at the back It is normal.
GB Ins tr uctions f or the Ins t aller Technical data Model/Type Gross capacity (l) Net capacity (l) Width (mm) Height (mm) Depth (mm) Energy consumption (kWh/24h) (kWh/year) Energy class, according to EU standards Freezing capacity (kg/24h) Rising time (h) Rated power (W) Weight (kg) Number of compressors - (ZLKI 301) Freezer: 105 Refrigerator: 195 Freezer: 80 Refrigerator: 192 600 1790 600 1,18 431 B 12 18 150 65 1 Installing the appliance Transportation, unpacking It is recommended to deliver the app
GB When placing the appliance ensure that it stands level. This can be achieved by two adjustable feet (1) at the bottom in front. 1-1 piece of distance washer (2) are accessories of the adjustable feet. If levelling the appliance requires, these washers can be removed. Do not stand the appliance on a sunny place or close to a radiator or cooker.
GB Following operations are to be done on the basis of figures and explanations: Break the circuit of the appliance. Tilt back the appliance carefully being careful so that the compressor cannot touch the floor. It is recommended to ask another person for help, who can keep the appliance at this position safely. Remove carefully (e.g. with a knife) the covering nails of screws fixing the bottom cover grid, then the cover grid can be removed by unscrewing the plate-screws (2 pieces).
GB S t or age time char t Time and method of storage of fresh foods in the refrigerator Foods Raw meat Cooked meat Roasted meat Raw minced meat Roasted minced meat Cold cuts, Vienna sausage Fresh fish Cooked fish Fried fish Tinned fish, open Fresh chicken Fried chicken Fresh hen Boiled hen Fresh duck, goose Roasted duck, goose Butter unopened Butter opened Milk in a plastic bag Cream Sour cream Cheese (hard) Cheese (soft) Curds Egg Spinach, sorrel Green peas, green beans Mushroom Carrot, roots Bell-pepper
GB War r ant y and ser vice Guarantee conditions Service and spare parts If calling the service is unavoidable, announce the trouble at a brand-mark service nearest to your place. When announcing the appliance has to be identified according to its data label. The data label of the appliance is stuck to the wall of the interior beside the vegetable box in the fresh food compartment in the bottom on the left side.
