INSTRUCTION BOOKLET MANUAL DE INSTRUCCIONES Tumble Dryer Secadora LTE 4400 125995040
CONTENTS Warnings ................................................Page 3 Description of the appliance ........Page 4 Installation .............................................Page 5 ■ Positioning.................................................Page 5 ■ Fitting the vent hose ..................................Page 5-6 ■ Door reversal .............................................Page 7 ■ Electrical connection .................................Page 7 ■ Stacking kit ............................
It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings.
DESCRIPTION OF THE APPLIANCE 1 2 3 4 5 6 07 08 09 10 11 12 4 3 1 Worktop Programme chart Low Temperature Button Buzzer OFF button Start button Control lights Mains-On Light Programme Selector Dial Rating Plate Door Handle Fluff filter Adjustable feet LTE 4400 ALGODON Y LINO EXTRA SECO SECO PARA GUARDAR SECO PARA PLANCHAR A BOTON REDUCCION TEMPERATURA B BOTON DE EXCLUSION ALARMA 6 5 7 8 MARCHA BOTON START C LUZ PILOTO DE SECADO LUZ PILOTO DE ENFRIAMIENTO SINTETICOS SECO PARA GUARDAR LUZ PILOT
ENGLISH INSTALLATION Positioning It is recommended that, for your convenience, the machine is positioned close to your washing machine. Whilst drying, the tumble dryer will expel a certain amount of warm, very moist air, and this should be removed from the room as quickly as possible to prevent condensation. In an extremely well ventilated room or close to an open window, this may occur naturally.
Advice: If the hose is long and the room temperature low, the moisture might condense to water inside the hose. This is an unavoidable natural phenomenon. To prevent this water from Iying in the hose or flowing back into the tumble dryer, it is advisable to drill a small hole (dia. 3 mm) in the lowest point of the hose and to place a small container below it.(See picture, point A).
ENGLISH Door reversal To make it easier to load or unload the laundry the door can be reversed. This operation must be carried out by qualified personnel. Operate as follows: - Remove the door by unscrewing the two screws (1) fastening the hinge to the cabinet (Fig. A). - Remove the safety catch (2) and the plug (3) by bending the two fastening tags (Fig. A). - Refit the safety catch (2) and plug (3) on the door by reversing their positions (Fig. B).
USE Control panel LTE 4400 ALGODON Y LINO EXTRA SECO A BOTON REDUCCION TEMPERATURA SECO PARA GUARDAR B BOTON DE EXCLUSION ALARMA SECO PARA PLANCHAR C BOTON START MARCHA LUZ PILOTO DE SECADO LUZ PILOTO DE ENFRIAMIENTO SINTETICOS SECO PARA GUARDAR LUZ PILOTO FIN DE PROGRAMA D LUZ PILOTO PUERTA ABIERTA SELECCION DEL TIEMPO 20-90 MIN.
Electronic Controlled Programmes Time Controlled Programmes These operate by means of dampness sensors. All you have to do is to set the selector dial for the programme required A, B, C or D and the laundry will be dried to the selected degree of dryness. The following are the degrees of final drying which can be obtained with electronic control: You can select a time up to 90 mins. to finish off drying, if necessary, or to use your tumble dryer independently of the electronic control system.
Drying programmes Electronic Controlled Programmes Type of laundry Degree of drying required Quantity A Extra dry Cotton & linen Store dry 5 kg Store dry B (*) C (*) Iron dry Synthetics Selector dial setting 2 kg D (*) (*) According to CEI 1121 standards.
ENGLISH i Drying sequence Before starting up for the first time it is advisable lo load a few moist cloths into the dryer and to let it run for about 20 minutes. This ensures that no dust and dirt is left in the drum. 1. Load the laundry Open the door by pulling the catch forwards. Load the items one at a time, shaking them out loosely and close the door. Please check the laundry does not get caught between the door and filter. P0305 2.
i ■ ■ ■ Useful hints Try to load to the maximum capacity of the machine as small loads are uneconomical. For information, here is a list of the average weights of some common laundry items.
ENGLISH MAINTENANCE You must disconnect the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. External cleaning Use only soap and water and then dry thoroughly. From time to time, apply a little wax furniture cream with a soft cloth. Important: do not use methylated spirit, diluents or similar products. Cleaning the door Clean periodically the interior part of the door to remove any fluff. Accurate cleaning ensures correct drying.
SOMETHING NOT WORKING? Problems which you can resolve yourself: PROBLEM ■ The dryer does not start up POSSIBLE CAUSE ■ ■ ■ ■ ■ ■ The dryer does not dry properly ■ ■ ■ ■ ■ The door is open. There is a power failure. The fuse is damaged. The start button has not been depressed. The drying programme or time has not been selected. The filter is clogged. An insufficient drying time has been selected. The selected programme is not suitable for the laundry. Excessive laundry load.
