Operation Manual

Working with precision | 109
To Do the following
Change the line color of margins Open the Margin line color picker, and choose a color.
Change the line style of margins Open the Margin line style picker, and choose a line style.
Set horizontal margins Type a value in the Horizontal margin box, click the Horizontal
margin button, and choose one of the following options:
•
Offset horizontally — creates a margin of the specified
distance around an object
•
Inset horizontally — creates a margin of the specified
distance within an object
•
Offset and inset horizontally — creates margins of the
specified distance around and within an object
Set vertical margins Type a value in the Vertical margin box, click the Vertical margin
button, and choose one of the following options:
•
Offset vertically — creates a margin of the specified
distance around an object
•
Inset vertically — creates a margin of the specified distance
within an object
•
Offset and inset vertically — creates a margin of the
specified distance around and within an object
Lock the ratio between vertical and horizontal margins
Click the Lock ratio button .
View only margin alignment guides
Disable the Object edges button , the Object centers button
, theIntelligent spacing button , and the Intelligent
dimensioning button .
Disable horizontal margins Click the Horizontal margin button, and choose No horizontal
margin .
Disable vertical margins Click the Vertical margin button, and choose No vertical
margin .
Using constrain keys
Constrain keys let you restrict how objects are drawn or edited. For example, when drawing a line, you can constrain it to be perfectly
horizontal or vertical. You can also change which key is used as the constrain key. You can change the constrain key from Ctrl to Shift, which
is the Windows standard.
