552 | Corel DESIGNER X7 User Guide
To Do the following
Select multiple nonadjacent colors Hold down Ctrl, and click the nonadjacent color swatches on the
color palette.
Edit a color Select the color you want to edit, click Edit, and modify settings in
the Select color dialog box.
Merge colors (Outline Trace) Select the colors that you want to merge, and click Merge.
If you want to specify how to merge the colors, click Options to
access the Options dialog box, and enable an option in the Merge
colors area.
Delete a color from a traced result (Outline Trace)
Select a color, and click the Delete color button .
The deleted color is replaced by the next color on the color palette.
Use a custom color palette
Click the Open color palette button , find the folder where the
palette is stored, and click a filename.
Color palettes have a .cpl filename extension.
Each color of the traced graphic is mapped to a similar color on the
custom palette.
Create a custom color palette from the edited color palette of a
traced result
Click the Save color palette button . In the Save palette as
dialog box, type a name in the File name box.
The number of colors cannot be reduced, and colors cannot be merged, when you use the Centerline Trace method.
To increase the number of colors in a traced result, you need to change the preset style or increase the amount of detail. For
information about how to change the preset style and the amount of detail, see “To fine-tune traced results” on page 549.
Setting default tracing options
You can enable any of the following tracing options.
• Quick Trace method — You can change the default Quick Trace settings to any preset style, or to the most recently used settings.
• Performance — This option determines how source bitmaps between 1 and 5 megapixels in size are handled, and how the quality of
the traced results is affected. The performance of PowerTRACE depends on the size and color depth of the source bitmaps as well as on
the available system memory. High-quality traced results require high-quality source bitmaps, which are often quite large. The larger the
source bitmap, the more resources are required. Bitmaps that are too large need to be downsampled before tracing, which may decrease
the image quality. To trace large bitmaps without sacrificing quality, you can set PowerTRACE to trace images as large as 5 megapixels
(provided RAM is sufficient). To achieve maximum performance, you can set PowerTRACE to prompt you to downsample bitmaps larger
that 1 megapixel.
• Merge colors — You can choose whether to merge colors in a traced result by averaging their values or by replacing the colors to be
merged with the first color you select.
