Installation Manual

36
35
E. Installing Rear-Facing
Check LATCH Belt
Tightness
Grasp the child restraint
at the belt path with one
hand. Push and pull the
child restraint from side to
side, forward and back. The
child restraint should not
move more than 1 inch.
NOTE: If it moves more than
an inch, try reinstalling the
child restraint or try another
seating location.
Secure your child in the
child restraint. Recheck the
recline angle to make sure it
is reclined according to your
child’s weight. Repeat steps
if not reclined correctly.
7.
Rear-Facing
For Children 5-22
(2.3-10 kg)
Top Line MUST Be
Level with the Ground
Rear-Facing
For Children 22-40 lb
s
(10.1-18 kg)
AND can sit
up unassisted
Recline range is between
the 2 level to ground
lines.
Review instruction manual.
4360-2154
To Remove LATCH Belt
From Vehicle Anchor
Remove child from child
restraint. Press down
firmly on adjuster side of
child restraint and press
release button to release
tension. Unhook LATCH
from bar by squeezing
spring lever and twist hook.
8.
It maybe easier to tighten the
LATCH belt through the belt
path opening as shown.
Rear-Facing
For Children 5-22 lb
s
(2.3-10 kg)
Top Line MUST Be
Level with the G
round.
4360-2155
Rear-Facing
For Children 22
-40 lbs
(10.1-18 kg)
AND can sit
up unassisted
Recline range is between
the 2 level to ground
lines.
Review instruction manual.
4360-2154
E-4 Install Rear-Facing with
Vehicle Belts
Do not use the LATCH system along with the
vehicle lap or lap/shoulder belt. Secure LATCH
belts when using the vehicle belts.
Check the vehicle belt before each use. Use
only if the belt is tightened properly and
securely.
Attach the top anchorage hook (tether) to the
child restraint’s seat back when used rear-facing.
Failure to follow these warnings can result in
serious injury or death.
Secure LATCH Belts
You MUST fasten the
LATCH belt hooks to the
side of plastic shells as
shown when using the
vehicle seat belts.
1.
Note: Review your vehicle’s owner manual for vehicle belt use.
Store Top Anchorage
Hook (Tether)
Attach the top anchorage
hook (tether) to the back
of shell as shown. Tighten
tether to remove the slack.
2.
