Installation Manual

51 52
Locate Locking Clip
Location
Grasp both vehicle belts
together just behind the
latch plate and unbuckle.
NOTE: If the latch plate
ends up just at the belt
path opening so you cannot
grasp the vehicle belt at the
latch plate, grasp the vehicle belts on the opposite side of the
child restraint, as close to the latch plate as possible. Install
the locking clip on the latch plate end, as close as possible.
Tighten Vehicle Belt
Push down firmly on the
child restraint and while
pulling on the vehicle
shoulder belt to tighten.
4.
5.
Attach Locking Clip
Thread both portions of the
vehicle belt onto the locking
clip, as close to the latch
plate as possible.
6.
Position Locking Clip
Position locking clip about
1 in. (2.5 cm) from vehicle
belt’s latch plate.
7.
Rebuckle Vehicle Belt
8.
9.
Check Vehicle Belt
Tightness
Grasp the child restraint
at the vehicle belt path
with one hand. Push and
pull the child restraint from
side to side, forward and
back. The child restraint
should not move more than
1 inch.
NOTE: If it moves more
than an inch, redo the steps
5 through 9 again or try
another seating location.
Secure your child in the
child restraint. Recheck
the recline angle to make
sure it is reclined according
to your child’s weight.
Repeat steps if not reclined
correctly.
Remove the locking clip
when the vehicle seat belt
is not being used with a
child restraint.
Rear-Facing
For Children 5-22 lbs
(2.3-10 kg)
Top Line MUST Be
Leve
l
wi
t
h the
Gro
und.
4360-2
155
Rear-Fac
ing
For Children 2
2-40 lbs
(10.1-18 kg)
AND can sit
up unas
s
isted
Recline range i
s b
etwe
en
the 2 level to ground
lines.
Revi
e
w instruction manual.
4360-2154
