Supplied with a 5’ cable, carrying case, windscreen, single

isolation clip, protective cap, and detachable connector.

COUNTRYMAN ASSOCIATES INC

B2D DIRECTIONAL

LAVALIER MICROPHONE

The B2D Directional Lavalier is easily the smallest directional lavalier in the

world, with the next smallest mic being more than twice its size. Combined

with exceptional sound quality and isolation, this tiny package opens up a new

set of miking options that were previously unavailable. The tight hypercardioid

pattern gives the B2D an extra 6-10 dB of headroom compared to an omni lav,

meaning less problems with feedback, ambient noise, room rumble, and phase

cancellations with multiple mics.

Positioning the B2D

With its small size and multiple

color and sensitivity options, the

B2D can easily hide behind a shirt

button, making it truly invisible

for ﬁlm work, theater, live shows,

or any other applications that

may otherwise have required the

reduced sound quality of under-

clothing miking.

Great for Broadcast

Natural vocal reproduction,

superb intelligibility and a

tight polar pattern make the

B2D ideal for broadcast and

a dependable workhorse you

can count on to perform night

after night in the most critical

applications.

Frequency Response : 50 Hz to 18 kHz

Cable Break Strength: > 45 pounds

Weight : .18 oz (5 grams)

The B2D Lavalier is available in three sensitivities:

B2DW4

standard (gray band) for most uses

Sensitivity: 6.0 mV/Pascal

Equivalent Acoustic Noise: 34 dBA SPL

Overload Sound Level: 120 dB SPL

B2DW5

mid (red band, -10 dB re W4) for loud vocals

Sensitivity: 2.0 mV/Pascal

Equivalent Acoustic Noise: 39 dBA SPL

Overload Sound Level: 130 dB SPL

B2DW6

low (blue band, -20 dB re W4) for operatic vocals

Sensitivity: 0.6 mV/Pascal

Equivalent Acoustic Noise: 44 dBA SPL

Overload Sound Level: 140 dB SPL

1 kHz Polar Response

Frequency Response

10030 1k 10k

20k

-10

-20

-30

Frequency (Hz)

Gain (dB)

90° O Axis, 8in

On Axis, 8in

300°

0°

330°

60°

30°

90°

120°

150°

240°

180°

210°

270°

-5

-10

-15

-20

hypercardioid cap

Summary of content (2 pages)

PAGE 1
COUNTRYMAN ASSOCIATES INC B2D DIRECTIONAL Supplied with a 5’ cable, carrying case, windscreen, single isolation clip, protective cap, and detachable connector. LAVALIER MICROPHONE The B2D Directional Lavalier is easily the smallest directional lavalier in the world, with the next smallest mic being more than twice its size. Combined with exceptional sound quality and isolation, this tiny package opens up a new set of miking options that were previously unavailable.
PAGE 2
B2D Directional Lavalier: Features and Use Isolation Clips Our isolation clips minimize clothing and vibration noise, while allowing 360 degree rotation of the mic for easy COUNTRYMAN ASSOCIATES INC positioning. We offer single and double isolation clips—as well as a magnetic isolation clip—in five different colors. Detachable Connectors The B2D detachable connectors interface to a wide variety of wireless transmitter packs or an XLR input.
