Bidet BA07-R/E • This product can not be used if the voltage is different from that mentioned in the rating plate. • For your safety and proper use of the product, please read this User’s Manual before use. • Warranty card is included in this User’s Manual. 1014692 BA07 »ç¿ë¼³¸í¼- ¹ÌÁÖÇâ_(08.09.10).
FEATURES 1. WIDE function Users can select the degree of the cleansing water spreading directly as the wanted step from the strong force of the flowing water to the softly spreading water. 2. Special function for the customer’s convenience - Power saving mode : Helps lower the utilities bill.
DEAR CUSTOMERS FOR INFORMATION SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . 4 Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . 4 Installation Safety . . . . . . . . . . . . . . . . . . . . . . 5 Operation Safety. . . . . . . . . . . . . . . . . . . . . . . 5 Others. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 HOW TO USE KEEP IN MIND . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 PREPARATIONS . . . . . . . . . . . . . . . . . . . . . . . . .
SAFETY INFORMATION Be careful to keep this safety information. Please read this information to prevent property loss and ensure your safety. If not observed, serious injury or even death may Danger occur as a result. If not observed, serious physical injury or property Warning damage may occur as a result. If not observed, minor physical injury or property damage Caution may occur as a result. Electrical Safety Do not use a damaged power cord or plug, and loose outlet.
A/S In the case the power cord is damaged, do not replace the cord yourself. Call Service Center to have it replaced. Otherwise, electric shock or fire may occur as a result. Do not install near a heating device. Avoid installing the product in places where the air is damp, dust is accumulated, or water drops. Otherwise, fire may occur as a result. Otherwise, electric shock or fire may occur as a result. Do not place or use the inflammable gases, nor the flammable materials near the product.
SAFETY INFORMATION Operation Safety Do not place an electric heater near the product or dispose of any flamed material such as lit cigarettes in the toilet. Do not place any containers with water, medicine, food, small metallic objects, or any flammable material on the top of the product. Otherwise, fire or product deformation may occur as a result. In the case foreign material gets inside the product, electric shock, fire, product damage may occur as a result.
Exercise caution not to have urine touch nozzles, air dryer outlet, or outside surface of the product. Otherwise, bad smell or malfunction may occur as a result. If the product is not to be used for a long time, pull out the power plug from the electrical outlet, close the main water supply valve, and drain the water in the water tank.
PARTS NAME Dimensions The toilet dimensions must be within those shown below. Do not install this product on a toilet that does not meet these dimensional requirements. 197.2 mm (7.76 inch) Round type 133.3 mm (5.25 inch) 400 mm (15.7 inch) 490 mm (19.3 inch) 376.7 mm (14.8 inch) 199 mm (7.83 inch) Elongate type 402.5 mm (15.9 inch) 490 mm (19.3 inch) 133.3 mm 406.7 mm (5.25 inch) (16 inch) Distance of fixing hall 133 mm (5.2 inch) ~ 206 mm (8.1 inch) 8 1014692 BA07 »ç¿ë¼³¸í¼- ¹ÌÁÖÇâ_(08.09.
For Information Front Seat cover Precautions sticker Water tank hose Tap water pipe Bidet hose T-shaped connector Bidet seat PARTS NAME Body Nozzle Indication part/ operation part Main water supply valve Rear Power plug Product sticker Drain hole Nano silver ceramic MF filter 9 1014692 BA07 »ç¿ë¼³¸í¼- ¹ÌÁÖÇâ_(08.09.10).
PARTS NAME Installation Material Bidet hose Fixing plate, 2 pc of Fixing sliders 2 pc of Fixing screws T-shaped connector 2 pc of Fixing rubbers 2 pc of Fixing washers Nano silver ceramic MF filter Rubber packing 2 pc of Fixing nuts Grounding This product must be grounded, in the event of an electrical short circus, ground reduces the risk of electrical hazards by providing an escape wire for the electric current. The power cord has grounding wire and a threeblade grounding plug (shown below).
Connect the power. Turn on by connecting the power plug to the electrical outlet and pressing the power selection button on the control panel. The bidet works normally only when the electricity is connected. Open the main water supply valve. The main water must be supplied to operate the bidet normally. Check whether the product is in power saving mode before use. - - When there isn’t a seat sensor sensing and a button operation, if you set the power saving mode.
PREPARATIONS Tips This product is for 120 V~ 60 Hz only. Please connect the power plug to a dedicated grounded electrical outlet for 120 V~ 60 Hz . After installation Please check whether the water leaks or not in the connection part of the T-shaped connection pipe. You must insert the rubber packing between the T-shaped connection pipe, the water pipe, and the water tank hose. Periodic filter replacement It is important to replace the filter periodically for the clean rinsing.
How To Use OPERATION/INDICATION PART Indication Part/Operation Part Indication part Operation part 2 Nozzle position button Rear cleansing function 3 selection button Front cleansing function selection button 4 Water pressure/air dryer 1 temperature indicator Air dryer function selection 6 button Water pressure/air dryer 5 temperature adjustment button WIDE function selection 2 indicator WIDE function selection 7 button PREPARATIONS / OPERATION/INDICATION PART Stop button 1 Move function selectio
OPERATION/INDICATION PART Indication Part 1 Water pressure/air dryer temperature adjustment indicator If you press the water pressure/the air dryer temperature adjustment button, the indicator is turned on in the step1step2step3 order. It is used as the water pressure adjustment indicator when you operate the rear cleansing/front cleansing function, and it is used as the air dryer temperature adjustment indicator when you operate the drying function.
7 WIDE function selection button Use it if you want to control the water ejection range when you use the cleansing function. You can select the range of the force of the flowing water of 3 steps as straight linestep1step2 using wide function selection button. Whenever you press the button, the indicator of the selected current ejection range is turned on. Use it to select the desired move function.
HOW TO USE For Rear Cleansing Rear cleansing Sit on the seat and press the rear cleansing function selection button on the remote control. - The cleansing water is ejected for about 1 minute and then automatically stopped. - An automatic nozzle cleaning is performed for about 5 seconds after cleansing when the nozzle retracts itself. Adjust the nozzle position by pressing the nozzle position button. Press the wide function selection button to adjust the desired water ejection range.
Front cleansing Move Press the move function selection button on the control panel. - The nozzle moves back and forth, providing a wider range of cleansing. It will be worked continuously while the cleansing function is operated. You can adjust the nozzle position by pressing the nozzle position button. To stop the move function, press the move function selection button again. Air dryer Press the air dryer function selection button on the remote control.
INSTALLATION Installing the product Tighten the fixing screws firmly so that the bidet body won’t be shaky on the toilet. Product installation place As the bidet is installed on the toilet, please install not to have water splashed on the bidet. After installation Keep the removed existing toilet seat in a shaded place to prevent its damage.
Maintenance Uninstallation Existing Toilet Seat 1. Remove the fixing nuts of the existing seat and separate the existing toilet seat 1 and the seat cover 2. 2 1 Installation the Product 1. Turn off the main water supply valve the existing water tank hose 2 . 1 and separate 2 1 2. Connect the rubber packing, T-shaped connector, and water tank hose in order to the existing tap water pipe. Please connect the bidet hose to the T-shaped connector.
INSTALLATION Installation the Product 5. Please install by adjusting the rear of the body to the fixing plates and pushing the product back. 6. Connect the T-shaped connector and the connected bidet hose to the bidet body. Please shorten the bidet hose as soon as possible. If the bidet hose is long, it may cause noises. 7. Open the main water supply valve. 8. Connect the power plug to the electrical outlet. Make sure to use a grounded electrical outlet.
Nozzles Tips 1. Press nozzle cleaning button on the right side of the bidet. The nozzle cleaning water is sprayed and the front cleansing nozzle sticks out to its full length. Clean the front cleansing nozzle. 2. Press nozzle cleaning button one more. - - The nozzle cleaning water is sprayed and the front cleansing nozzle retracts itself, and the rear cleansing nozzle sticks out to its full length. Clean the rear cleansing nozzle. 3.
CLEANING METHOD Uninstallation the Product 1. Unplug the power plug from the outlet. 2. Close the main water supply valve. 3. Place a big wash basin (1 L or more) under the rear drain hole of the bidet. 4. Turn the drain stopper 1 counter clockwise by 90 ° and pull out it in the direction of the arrow 2 to remove it. - Please assemble the drain stopper to the product again after draining. 1 2 5. Please separate the product from the fixing plate by pulling out it forward.
It is recommended to check the status of the bidet frequently in order to use the bidet safely. Please check the following items frequently to maintain the status of the bidet at its best. Maintenance MAINTENANCE Freezing protection function Check that the power is turned on. If the power is turned off, the anti-freezing program does not work and the bidet may have freezing burst or malfunctions in a cold environment.
FILTER REPLACEMENT METHOD 1. Please unplug the power plug and turn off the main water supply valve. 2. Separate the MF filter from the filter holder by rotating the MF filter to replace to the arrow direction. 3. Please rotate and insert new MF filter to the filter holder like the next arrow direction to the end not to be shaken. 4. Use it after opening the main water supply valve and plugging in the cord. 24 1014692 BA07 »ç¿ë¼³¸í¼- ¹ÌÁÖÇâ_(08.09.10).
TROUBLESHOOTING Check • Is the power plug connected to the electrical outlet? Plug in the power cord. • Is it a power failure? Check whether it is a power failure. • Is the control panel turned off? Check whether buttons other than the Power button work well. If one of the other buttons is pressed down, the Power button does not work. In this case, call our service center. • Does the main water supply valve closed? Open the main water supply valve.
TROUBLESHOOTING Symptom The air from the air dryer is cold. Water leaks in areas other than the nozzles. Water comes out while the bidet is not in use. If you plug in the power cord, the rear cleansing nozzle come out and go in. There is a noise coming from the bidet. Tips Check Measures to take • Isn’t the air dryer temperature adjustment button set to “OFF” status? Please adjust as the proper temperature by pressing the air dryer temperature adjustment button.
SPECIFICATION BA07-R/E Power rating 120 V~ 60 Hz Power consumption 850 W Power cord 1.2 m (47 inch) long Water pressure 490 mm (W) X 510 mm (D) X 150 mm (H) BA07-E 490 mm (W) X 540 mm (D) X 150 mm (H) Weight (NET) Warm water cleansing device Warm air dryer Warm seat MF filter Accessories 0.075 MPa - 0.68 MPa BA07-R 5.7 kg Rear cleansing Maximum 0.7 L/min, automatic nozzle cleaning function Front cleansing Maximum 0.
MEMO 28 1014692 BA07 »ç¿ë¼³¸í¼- ¹ÌÁÖÇâ_(08.09.10).
MEMO Others 29 1014692 BA07 »ç¿ë¼³¸í¼- ¹ÌÁÖÇâ_(08.09.10).
WARRANTY CARD OR WARRANTY LETTER ONE YEAR LIMITED WARRANTY BIDET BA07-R/E (“PRODUCT”) Model : Serial Number : Customer Name : Date of Purchase : (“OWNER”) What This Warranty Covers : Limitations and Exclusions : Commencing with the date of purchase of the Product and continuing for a period of one year, if manufacturing defects in the Product cause the Product to not operate properly for its intended use, then subject to the exclusions, conditions, and limitations contained herein, COWAY at its sole opt
Others Waiver : Any implied warranty of merchantability or fitness for a particular purpose or use, shall be limited to the duration of the foregoing express written warranty. COWAY’s failure at any time to enforce or rely upon any of the terms or conditions stated herein shall not be construed to be a waiver of its rights hereunder.
