Product Name

Woongjin bidet

BA08-AR/AE

AC 120V/60Hz

850W

1.2m(47inch)

0.11~0.68M Pa(1.0~7.0kgf/



)

525(W)x500(D)x142(H)mm

525(W)x530(D)x142(H)mm

6.2~6.8kg

max. 0.7



/min, nozzle auto cleaning function

max. 0.7



/min, nozzle auto cleaning function

Rear cleansing 1 min, Front cleansing 1 min, Air dryer 2 min

Mycom control, 3 level control

3 level spray range control(Straight-level 1-level 2)

Air and water mixture stream

4 levels(off: room temperature, low:33, medium:36, high:39)

800W



Bi-metal, temperature sensor, temperature fuse(over heating prevention)

3 levels

Air dry 2min

180W

Bi-metal, temperature fuse(over heating prevention)

4 levels(off: room temperature, low:34, medium:37, high:40)

50W

Temperature sensor, temperature fuse(over heating prevention)

4months(2.5ton/month, impurity rate: under 0.5NTU)

(L)136 x ( ) 48mm

T-shaped connector 1ea, Bidet hose 1ea, Fixing washer 2ea, Fixing bolt

2ea, Fixing nut 2ea, Fixing rubber 2ea, Rubber packing 3ea, MF filter

1ea, Holder filter 1ea, Clip filter plastic 1ea, Battery 2ea

Nozzle position control, Move, Nozzle cleaning, Remote control function, Mute,

Seat locking mode, Main body/ Remote control auto power saving mode

0~40

Model Name

Power rating

Power consumption

Power cord

Water pressure

Product

dimensions

Weight (NET)

Rear cleansing

BA08-AR

BA08-AE

Front cleansing

Timing

Water pressure control

Wide (spray range control)

Air

Water temperature control

Power consumption of cistern heater

Cistern capacity

Safety device

Warm air temperature control

Timing

Power consumption of dryer heater

Safety device

Seat heating control(after seating)

Power consumption of heater

Safety device

Life span

Dimension

Installation materials

Warm

water

cleansing

device

Warm air

dryer

Warm

seat

MF filter

Accessories

Other function

Temperature

 Manufactured by WOONGJIN CUCHEN CO.,Ltd

 These specifications may be changed to improve the performance of the product.

 Earlier clogging may occur in MF filter depending on quality and consumption of water.



Please read this manual for a proper operation of

WOONGJIN BIDET.



The strictly precise company, WOONGJIN BIDET,

actualizes the 'Quality First' principle.

The warranty document is enclosed in this manual.

USER'S MANUAL FOR WOONGJIN

‘’BIDET

BA08-AR/AE

Summary of content (18 pages)
