Installation Guide

www.coyoteoutdoor.com
DIMENSIONAL RENDERINGS
Model No. Gas Supply BTU's Regulator WC Pressure Max PSI Electrical Requirements
C2C36LP Propane 80,000
1/2" Female Pipe
11" .5 PSI Qty 1 - 120 VAC 60 Hz Grounded Plug
C2C36NG Natural Gas 80,000
20 lb Tank Regulator
4" .5 PSI Qty 1 - 120 VAC 60 Hz Grounded Plug
Model No. Height Width Depth
Model No. Height Width Depth
C2C36
C2C36
23"
CJAKTCS36
11"
CJAKTCS36
23"
Cutout Dimensions for Island
Overall Product Dimensions
 When using a Coyote insulated jacket, you will want to build your island to the jackets Cutout and Overall Dimensions
listed above (detailed on 2nd page). Once the jacket is installed, the grill will rest on/inside the insulated jacket
35
3
/4"
20
1
/2"
25
1
/2"
10
1
/4"
11"
37
5
/8"
22
1
/8"
32
1
/2"
35
1
/2"
C
2C36 INSTALL GUIDE
Important Note to Installer: This file is not intended to replace your Owners' Manual which contains specific safety
requirements and consumer guidelines. Please refer to your Owners' Manual prior to installing or operating your built-in grill.
11"
23"
35
3
/4"
37
5
/8"
22
1
/8"
