Installation Guide

13
14
15
18
17
19
20
21
22
23
25
24
26
27
PLEASE READ AND SAVE FOR FUTURE REFERENCE.
CAUTION
1. Turn off the main power at the circuit breaker before installing the fixture in order to prevent possible shock.
2. All electrical connections must be in accordance with local and National Electrical Code (N.E.C.) standards. If you are
unfamiliar with proper electrical wiring connections obtain the services of a qualified electrician.
GENERAL
Remove all parts and hardware from the box and make sure that none are missing by referencing the illustrations provided.
Bulbs Required (not included): 3 Medium Base 60 Watt Max. (for 3-light semi-flush)
Customer Service: 1 [phone]
KENSWICK #35453-PR
1
3
2
4
5
6
7
8
9
10
12
11
34
32
33
28
29
3-LIGHT CONVERTIBLE (SEMI-FLUSH)
1. OUTLET BOX (not included)
2. MOUNTING PLATE
3. OUTLET BOX SCREWS and WASHERS
(pre-attached to outlet box)
4. BLACK SUPPLY WIRE (not included)
5. SMOOTH (or BLACK) FIXTURE
LEAD WIRE
6. WHITE SUPPLY WIRE (not included)
7. RIBBED (or WHITE) FIXTURE
LEAD WIRE
8. SUPPLY GROUND WIRE (not included)
9. FIXTURE GROUND WIRE
10. WIRE CONNECTORS
11. GROUND SCREW (pre-attached)
12. FIXTURE SCREWS and HEX NUTS
(pre-attached)
13. COVER
14. FIXTURE
15. DECORATIVE NUTS (pre-attached)
16. CENTER STEM
17. ALABASTER GLASS SHADE
18. CLEAR GLASS SHADE
19. HEX NUT (pre-attached)
20. RUBBER WASHERS (pre-attached to
decorative screws)
21. DECORATIVE SCREWS (pre-attached)
22. RODS
23. DIFFUSER PLATE
24. STEEL WASHERS (pre-attached)
25. RUBBER WASHER, top (pre-attached)
26. FINIAL PLATE
27. FINIAL (pre-attached)
28. DECORATIVE NUTS (for cover)
29. DECORATIVE NUT SCREWS (pre-attached)
30. FIXTURE LOOP
31. FIXTURE THREADED ROD
32. RUBBER WASHER, bottom (pre-attached)
33. STEEL WASHER (pre-attached)
34. HEX NUT (pre-attached)
30
31
13
12
16
(remove)
