Installation Guide

PLEASE READ AND SAVE FOR FUTURE REFERENCE.
CAUTION
1. Turn off the main power at the circuit breaker before installing the fixture in order to prevent possible shock.
2. All electrical connections must be in accordance with local and National Electrical Code (N.E.C.) standards. If
you are unfamiliar with proper electrical wiring connections, obtain the services of a qualified electrician.
GENERAL
Remove all parts and hardware from the box and make sure that none are missing by referencing the illustrations
provided.
Bulbs Required (not included): 1 Medium Base 100 Watt Max.
Customer Service: 1 [phone]
P550BNK1 / P550OB1 / P550TS1
P555BNK1 / P555OB1 / P555TS1
P560BNK1 / P560OB1 / P560TS1
P565BNK1 / P565OB1 / P565TS1
1-LIGHT MINI PENDANT
1. OUTLET BOX (not included)
2. MOUNTING PLATE
3. OUTLET BOX SCREWS and WASHERS
(pre-attached to outlet box)
4. BLACK SUPPLY WIRE (not included)
5. SMOOTH (or BLACK) FIXTURE LEAD WIRE
6. WHITE SUPPLY WIRE (not included)
7. RIBBED (or WHITE) FIXTURE LEAD WIRE
8. FIXTURE GROUND WIRE
9. SUPPLY GROUND WIRE (not included)
10. WIRE CONNECTORS
11. CANOPY
12. FIXTURE SCREWS and HEX NUTS (pre-attached)
13. GROUND SCREW (pre-attached)
14. DECORATIVE NUTS (pre-attached)
15. SWIVEL ASSEMBLY (pre-attached)
16. 12 INCH RODS
17. 6 INCH RODS
18. FIXTURE
19. SHADE
20. SOCKET RING (pre-attached)
1
5
2
3
9
6
7
4
10
13
12
12
8
20
11
15
16
17
14
18
19
