Owner`s manual

PRODUCTSPECIFICATIONS
GASOLINE 1.25
CAPACITY UNLEADED
ANDTYPE: REGULAR
OILTYPE SAE 30 (ABOVE 32°F
'API-SF- SJ): SAE 5W-30
(BELOW 32°F)
OIL CAPACITY: 3.0 PINTS
SPARK PLUG: CHAMPION RC12YC
(GAP: .030")
VALVE INTAKE:. .003"- .005"
CLEARANCE: EXHAUST: .005"-.007"
GROUND SPEED (MPH):
FORWARD: 1ST 1.1
2ND 1.4
3RD 2.2
4TH 3.3
5TH 4.4
6TH 4.9
REVERSE: 1.4
TIRE PRESSURE: FRONT: 14 PSI
REAR: 12 PSI
CHARGING 3 AMPS BATTERY
SYSTEM: 5 AMPS
HEADLIGHTS
BATTERY: AMP/HR: 25
MIN. CCA: 190
CASE SIZE:U 1R
BLADE BOLT TORQUE: 27-35 FT. LBS
CONGRATULATIONS on yourpurchase
of a new tractor. It has been designed,
engineeredand manufactured to give
you the best possibledependabilityand
performance.
Should you experience any problemyou
cannot easilyremedy,pleasecontacta
Sears or otherqualifiedservicecenter.
We have competent,well-trainedtechni-
cians andthe propertoolsto serviceor
repairthistractor.
Please read and retainthismanual. The
instructionswillenable you to assemble
and maintainyourtractorproperly.
Always observethe =SAFETYRULES".
REPAIR AGREEMENT
A RepairAgreementis availableon this
product.ContactyournearestSears
storefordetaJls.
CUSTOMER RESPONSIBILITIES
• Read and observe the safety rules.
• Follow a regular schedule in maintain-
ing, cadng for and using your tractor.
• Follow the instructions under "Mainte-
nance" and =Storage" sections of this
owner's manual.
,_WARNING: This tractor is equipped
with an internal combustion engine and
should not be used on or near any
unimproved forest-covered, brush-
covered or grass-covered land unless the
engine's exhaust system is equipped with
a spark arrester meeting applicable local
or state laws (if any). If a spark arrester is
used, it should be maintained in effective
working order by the operator.
In the state of California the above is
required by law (Section 4442 of the
California Public Resources Code).
Other states may have similar laws.
Federal laws apply on federal lands. A
spark arrester for the muffler is available
through your nearest Sears service
center (See REPAIR PARTS section of
this manual).
6
