VC-6112/6210/6212 Vintage Club Amplifier OWNER’S MANUAL
VC-6112/6210/6212 Amplifier Congratulations! You are now the proud owner of one of the newest and most versatile tube amplifiers available for the guitar! The CRATE Vintage Club Series offers flexibilty and portability with two separate channels for a uniqely rich palette of tonal variety and simplicity of control over your sound. Your CRATE Vintage Club Series amplifier is musician-made in the U.S.A. using the finest components available.
VC-6112/6210/6212 Amplifier TABLE OF CONTENTS: Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 The Front Panel Controls and Their Use . . . . . . . . . . .4 The Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Connecting to the Insert Jack . . . . . . . . . . . . . . . . . . .5 Some Suggested Settings . . . . . . . . . . . . . . . . . . . . .6 System Block Diagram . . . . . . . . . . . . . . . . . . . . . . . .7 Technical Specifications . . . . . . . . .
VC-6112/6210/6212 Amplifier 1 2 3 45 6 7 8 9 10 11 12 13 14 15 16 The Front Panel Controls and Their Use: 1. INPUT JACKS: The High input is a direct connection for “standard” electric guitars. The Low input is padded 6dB and is best suited for guitars with “hot” pickups or on-board active electronics. (Use a high quality shielded instrument cable.) 2. CHANNEL SWITCH: Toggle this switch to the desired channel: up for Channel A, down for Channel B.
VC-6112/6210/6212 Amplifier SPEAKERS TO REPLACE THE RISK OF FIRE, REPLACE FUSE WITH SAME TYPE AND RATING. MODEL: VC-6212 SERIAL: VC-62120000001 MODEL VC-60 LINE: V~ Hz WATTS: MAX SERIAL # A EFFECTS LOOP 60 WATTS RMS BIAS UTILISER UN FUSIBLE DE RECHANGE DE MEME TYPE. ADJUST IMPEDANCE SELECTOR SPEAKER IMPEDANCE MUST MATCH SELECTED AMPLIFIER IMPEDANCE RETURN SEND MADE IN THE U.S.A. BY SLM ELECTRONICS 1400 FERGUSON AVENUE, ST. LOUIS, MO 63133 FOOTSWITCH T.P.
VC-6112/6210/6212 Amplifier Some Suggested Settings: Nice ’n Clean: Good ’n Crunchy: Jazz Tone: Bright ’n Crunchy: Strong Blues: Viola: It Goes to “12”: Blitzkreig: *Set Reverb to taste 6
VC-6112/6210/6212 Amplifier System Block Diagram: TRBL HI INPUT STAGE MID BASS GAIN GAIN STAGE GAIN STAGE MID LOW BOOST BOOST MSTR VOL. TRBL LOW MID MSTR BASS VOL.
VC-6112/6210/6212 Amplifier TECHNICAL SPECIFICATIONS: Output Power Rating 60W RMS @ 10% THD, 16 ohm load, 120 VAC Input Impedance 1 M ohm Maximum Signal Accepted 0dB: 1.5V peak to peak; -6dB: 2.8V peak to peak Gain Channel A: Channel B: 68dB 100dB Tone Control Range Channel A: Treble: Mid: Bass: Mid Boost: Low Boost: Treble: Mid: Bass: Bright: Mid Boost: Presence: Channel B: Both Channels Effects Send 16dB @ 5Hz 8dB @ 700Hz 10dB @ 50Hz 12dB @ 800Hz 13dB @ 100Hz 16dB @ 2.
