PM62S/PM82S/PM82T Powered Mixers

Technical Specifications

Due to ongoing product development and improvement, the specifications contained herein are subject to change without notice.

MAXIMUM VOLTAGE GAIN 87dB Mic In to Power Amp Out Main 1, 2 and Monitor

(PAD OFF) 59dB Mic In to Main Out, Monitor Out

64dB Mic In to Effect Out

47dB Mic In to Rec Out

47dB Line In to Main Out, Monitor Out

26dB Aux In to Main Out, Left (Mono), Right

17dB Stereo Left/Mono to Main

INPUT CHANNEL EQUALIZATION ±15dB Maximum

High: 12kHz (shelving); Mid: 2kHz (peaking); Low: 80Hz (shelving)

FREQUENCY RESPONSE +1/-3dB, 20Hz-20kHz @ 1W output into 8 ohms (Power Amp Out)

+1/-3dB, 20Hz-20kHz @ +4dB output into 10k ohms (Main Out, Monitor Out, Effects Send)

MAXIMUM OUTPUT POWER PM62S, PM82S: 2 X 400W/4 ohms @ 0.5% THD @ 1kHz

PM82T: 3 X 270W/4 ohms @ 0.5% THD @ 1kHz

TOTAL HARMONIC DISTORTION <0.3% @ 20Hz-20kHz, 100W output into 4 ohms (Power Amp Out)

<0.3% @ 20Hz-20kHz, +14dB output into 10k ohms (Main Out, Monitor Out, Effects Send)

HUM AND NOISE -115dB equivalent input noise, -53dBv residual output noise

(Average, Rs=150Ω) (Power Amp Out)

(with 20Hz-20kHz BPF) -74dBv residual output noise (Main Out, Monitor Out, Effects Send)

-71dBv (75dB S/N) (Main Out, Monitor Out) All channel Level controls at minimum

-67dBv (72dB S/N) (Main Out, Monitor Out) One channel Level control at maximum

-73dBv (77dB S/N) Effects Send All channel Level controls at minimum

-62dBv (66dB S/N) Effects Send One channel Level control at maximum

CHANNEL CROSSTALK @ 1kHz < -90dB

GRAPHIC EQUALIZER +/-12dB @ 60Hz, 120Hz, 360Hz, 1kHz, 2.5kHz, 7kHz, 16kHz

INTERNAL DIGITAL EFFECT 16 programs

PHANTOM POWER +48V is supplied to electrically balanced inputs for powering condenser microphones via 6.8kΩ current

limiting/isolating resistors

LIMITER LED ON Output Level: +34dBv

FOOT SWITCH DSP On/Off

POWER CONSUMPTION 1500W

SIZE AND WEIGHT PM62S: 19” (483mm) W x 13” (330mm) H x 11” (279mm) D; 49 lbs (22kg)

PM82S: 21.25” (540mm) W x 13” (330mm) H x 11” (279mm) D; 51 lbs (23kg)

PM82T: 21.25” (540mm) W x 13” (330mm) H x 11” (279mm) D; 52 lbs (24kg)
