Assembly Instruction

HARDWARE

TOOLS REQUIRED

COMPONENTS

1 A) Remove 2 small bolts (pre-installed) from chaise

assembly using a phillips head screwdriver.

B) Insert pin of wheel into corresponding hole of chaise

assembly as shown. Align hole in pin with hole in leg.

Secure wheel to chaise assembly with 1 small bolt using

a screwdriver. Make sure wheel is securely engaged by

bolt. Do not over tighten the bolt. Repeat steps for remain-

ing wheel.

Assembly is now complete.

ASSEMBLY

NOTE: Do not over

tighten the bolts

Made in China - r03 Page 1 of 2

Thank you for purchasing the Alfresco Chaise Lounge.

This page lists all the contents included in the box. Please

take time to identify the hardware as well as the individual

components of this product. As you unpack and prepare

for assembly, place the contents on a carpeted or padded

area to protect them from damage.

Note: 2 people are required to safely assemble this product.

ALFRESCO CHAISE LOUNGE

Missing hardware? Please call 800.606.6387 for replacements.

2 - small bolts

(pre-installed)

2 - wheels

1 - chaise assembly

(We recommend the use of hand tools instead of power tools)

chaise assembly

wheel

small bolt

Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com

phillips head screwdriver

PAGE 1
ALFRESCO CHAISE LOUNGE HARDWARE 2 - wheels 2 - small bolts (pre-installed) Missing hardware? Please call 800.606.6387 for replacements. COMPONENTS 1 - chaise assembly Thank you for purchasing the Alfresco Chaise Lounge. This page lists all the contents included in the box. Please take time to identify the hardware as well as the individual components of this product. As you unpack and prepare for assembly, place the contents on a carpeted or padded area to protect them from damage.
PAGE 2
ALFRESCO CHAISE LOUNGE ADJUSTING SEAT BACK seat back lever Pull lever out from underside of assembly, adjust seat back to desired height. Release lever to lock seat back into position. Assembly is now complete. CLEANING & CARE Clean surfaces with a dry or damp soft cloth. Do not use abrasive cleaners. It is recommended to cover the chaise if left outdoors for the winter. To remove small scratches, trays can be lightly sanded with a 0000 extra fine steel wool or very fine sand paper.
