User Guide

Wall Mount Back Box Crestron BB-4L
The dimensions of the BB-4L are shown in the following diagram.
Dimensional Drawing (Fully Assembled without Cover Plate)
0.03 in
(0.08 cm)
6.93 in
(17.60 cm)
5.00 in
(12.70 cm)
8.27 in
(21.01 cm)
3.90 in
(9.91 cm)
6.00 in
(15.24 cm)
4.50 in
(11.43 cm)
3.31 in
(8.41 cm)
BACK BOX (ASSEMBLED)
COVER PLATE
2
• Wall Mount Back Box: BB-4L Installation Guide - DOC. 6387
