Crestron C2N-ANLZ Cresnet® Analyzer Operations Guide
This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2006 Crestron Electronics, Inc.
Crestron C2N-ANLZ Cresnet® Analyzer Contents Cresnet® Analyzer: C2N-ANLZ 1 Introduction ............................................................................................................................... 1 Features and Functions ................................................................................................ 1 Applications................................................................................................................. 1 Specifications .........................
Cresnet® Analyzer Crestron C2N-ANLZ ® Cresnet Analyzer: C2N-ANLZ Introduction Features and Functions • • • • • Cresnet® Analyzer records Cresnet data at customer installations for analysis by Crestron engineers Logs Cresnet traffic and assesses the Cresnet network Dual power – Cresnet Power (24 VDC) or included 9 Volt battery backup Logs analyzed data to included 512MB (expandable to 1GB) multimedia memory card (MMC); USB 2.
Cresnet® Analyzer Crestron C2N-ANLZ Specifications Specifications for the C2N-ANLZ are listed in the following table.
Cresnet® Analyzer Crestron C2N-ANLZ Physical Description This section provides information on the connections, controls, and indicators available on your C2N-ANLZ. C2N-ANLZ Physical View Operations Guide – DOC.
Cresnet® Analyzer Crestron C2N-ANLZ C2N-ANLZ Overall Dimensions 6 1 2 3 4 5 3.13 in (7.94 cm) 1.25 in (3.18 cm) 3.80 in (9.65 cm) 7 8 Connectors, Controls, & Indicators # CONNECTORS, CONTROLS, & INDICATORS DESCRIPTION 1 PWR Light Emitting Diode (LED) Indicates the state of operation of the C2N-ANLZ. Refer to “Operational Status” on page 10 for more information. 2 NET LED 3 MARKER 1 & 2 BUTTONS Indicates Cresnet activity on the Cresnet bus.
Cresnet® Analyzer Crestron C2N-ANLZ Connectors, Controls, & Indicators (continued) # CONNECTORS, CONTROLS, & INDICATORS DESCRIPTION 4 LOG BUTTON The LOG button starts and stops data logging to the memory card. Refer to “Log Data to a Memory Card” on page 10 for more information. 5 INIT BUTTON The INIT button initializes and formats the memory card. Refer to “Format a Memory Card” on page 10 for more information. 6 MEMORY Memory card slot for included removable multimedia memory card.
Cresnet® Analyzer Crestron C2N-ANLZ Industry Compliance As of the date of manufacture, the C2N-ANLZ has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules.
Cresnet® Analyzer Crestron C2N-ANLZ Setup Network Wiring When wiring the network, consider the following: • Use Crestron Certified Wire. • Use Crestron power supplies for Crestron equipment. • Provide sufficient power to the system. CAUTION: Insufficient power can lead to unpredictable results or damage to the equipment. Please use the Crestron Power Calculator to help calculate how much power is needed for the system (http://www.crestron.com/calculators).
Cresnet® Analyzer Crestron C2N-ANLZ Memory Card When installing the memory card, observe the following: • Insert the memory card with electrical contacts facing up. • Push in the memory card until it clicks into the socket. • The memory card should only be inserted or removed when the LOG LED is off. Battery The C2N-ANLZ has a 9 Volt battery that is used as a backup in the absence of Cresnet power.
Cresnet® Analyzer Crestron C2N-ANLZ Uploading and Upgrading Crestron recommends using the latest programming software and that each device contains the latest firmware to take advantage of the most recently released features. However, before attempting to upload or upgrade, it is necessary to establish communication. Establishing Communication Use Crestron Toolbox for communicating with the C2N-ANLZ; refer to the Crestron Toolbox help file for details.
Cresnet® Analyzer Crestron C2N-ANLZ Operation The C2N-ANLZ can be operated from the buttons on the device or via console commands from a connected PC. Button Operation Using the buttons on the C2N-ANLZ, you can: Operational Status Format a Memory Card Log Data to a Memory Card • Format a memory card • Log Cresnet data to a memory card • Mark events in the log The PWR LED indicates the operational status of the C2N-ANLZ: • Off: The C2N-ANLZ is sleeping • Blink: Operating from 9 Volt battery.
Cresnet® Analyzer Crestron C2N-ANLZ Mark Events in the Log When troubleshooting, events can be marked in the log for future analysis. To mark events while logging: • Start logging data as described above. • Press either of the MARKER buttons to place a marker in the log. Pressing the MARKER 1 button will place the text “MARK 1” in the log file. Pressing the MARKER 2 button will place the text “MARK 2” in the log file. When a marker button is pressed, its corresponding LED will light.
Cresnet® Analyzer Mark Events in the Log Crestron C2N-ANLZ When troubleshooting, events can be marked in the log for future analysis. When the engineer reviews the log, he/she can search the log for the marker to locate the instance that requires the engineer’s analysis. To mark events while logging: • While the C2N-ANLZ is logging data, enter the console command MARK 1 to place the text “MARK 1” in the log file.
Cresnet® Analyzer Crestron C2N-ANLZ Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. C2N-ANLZ Troubleshooting TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION Device does not function. Device is not receiving power. Check that NET 1 connector is connected to a Crestron control system or a Crestron 24 VDC power supply. PWR LED does not illuminate.
Cresnet® Analyzer Crestron C2N-ANLZ When calculating the length of wire for a particular Cresnet run, the wire gauge and the Cresnet power usage of each network unit to be connected must be taken into consideration. Use Crestron Certified Wire only. If Cresnet units are to be daisychained on the run, the Cresnet power usage of each network unit to be daisy-chained must be added together to determine the Cresnet power usage of the entire chain.
Crestron C2N-ANLZ Cresnet® Analyzer Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange, or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number.
